Performance
- Suitable for Processor
- Cooler Type
- Fan Diameter: 120mm
- Supported Processor Sockets: LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket FM1, Socket FM2
- Processor: AMD A, Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
- Rotation Speed (min): 600RPM
- Rotation Speed (max): 1400RPM
- Noise Level (high speed): 26dB
- Airflow: 59.47m³/h
- Maximum Air Pressure: 0.5mmH2O
- Pulse Width Modulation (PWM) Support: YES
Design
- Product Color: Black, Orange
- Number of Fans: 1 fan(s)
- Number of Fan Blades: 9
- Number of Heat Pipes: 4
Connectivity
- Fan Connector: 4-pin
Power Management
- Rated Voltage: 12V
- Rated Thermal Design Power (TDP): 150W
Weight and Dimensions
- Width: 127mm
- Depth: 83mm
- Height: 155mm
- Weight: 560g
- Fan Dimensions (W x D x H): 120 x 25 x 120mm
- Heat Pipe Diameter: 6mm
- Package Width: 150mm
- Package Depth: 110mm
- Package Height: 175mm
- Package Weight: 715g
Main Specifications
- Type
- Active
- Socket
- 1366, AM2, AM2+, AM3, AM3+, AM4, FM1, FM2, 1150/1151/1155/1156
- Dual Fan
- No
- Colour
- Orange
Technical Specifications
- Minimum Noise Level
- 26 dB
- RPM (Full Load)
- 1400 rpm
- Thermal Design Power (TDP)
- 150 W
Dimensions
- Width
- 127 mm
- Length
- 83 mm
- Height
- 155 mm
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
