Power Capability

• High Mode: 2 x 8 W RMS
• Low Mode: 2 x 5 W RMS

Frequency Response

• 10 Hz - 80 kHz @ 5 W 0 / -3 dB

Total Distortion

• 0.5% at 3 W into 4 Ohms

Signal to Noise Ratio

• - 110 dB / 8 W

Load Commercial Speaker Contact

• 3 - 32 Ohms (BIAS High - Low)

Load Commercial Headphone Contact

• 6 - 2000 Ohms (OUT Low - High)

Gain

• 26 dB

Connections

• Inputs: 2 x Line Level / RCA
• 1 x XLR Line Level
• Outputs: 1 x Speaker Output
• 1 x Headphone Output 6.3 mm jack
• 1 x Headphone Output 4 pin XLR
• 1 x Regulated Preamp Output RCA (optional factory only)

Features

• ECO Mode, Power Management

Preamplifier

Input Sensitivity

• 400 mV

Input Resistance

• 50 kOhms / Cinch, 25 kOhms / XLR

Left/Right Separation

• 40 dB

Input/Input Separation

• > 90 dB

Pre Out Output Resistance

• 40 Ohms

Maximum Pre Out Level

• 5 V RMS

Preamplifier Tube Complement

• 1 x ECC 82, 2 x EF 800

General Information

Power Consumption

• 120-200 W idle, 200 W @ full power

Weight

• 19 kg

Main Accessories

• Power cable, IR-Remote Control, Allen key for disassembling the cover

Main Fuse

• 230/240 V main: 2.5 A slow-blow type H

Dimensions (in mm)
