The Arcam PA410 is a four-channel power amplifier that belongs to the brand's high-performance cinema product line, designed to deliver exceptional performance.
Full Immersion
Enjoy full immersion with the immense power offered by this amplifier, providing 4 channels of reliable Class AB amplification. With an impressive 70W per channel, the PA410 is capable of offering great flexibility and power while maintaining control.
Arcam Sound Quality
Arcam is known for high-performance audio products and uses only top-quality materials and specialized engineering. The PA410 is no exception to this reputation, featuring the best quality materials including a toroidal transformer power supply, sound-absorbing materials, and parallel transistor outputs. It supports audio playback with minimal levels of vibration and distortion, ensuring a pleasant listening experience every time.
Main Features
- Four-Channel Power Amplifier
- 4 x 70W Class AB amplification (all channels driven)
- Toroidal transformer
- Ethernet, RS232 control
Technical Specifications
- Continuous power output at 0.2% THD per channel
- Four channels at 4Ω / 8Ω, 20Hz – 20kHz: 70W / 50W
- Two channels at 4Ω / 8Ω, 20Hz – 20kHz: 90W / 60W
- Total distortion, 80% power, 8Ω at 1kHz: 0.003%
- Input sensitivity inputs: 50W / 8Ω 600mV RMS
- Signal-to-Noise Ratio: (A-wtd) 50W / 8Ω 105dB
- Input impedance: 10kΩ
- Frequency response: 20 - 20kHz +/-0.05dB
General
- Mains voltage: 110–120V or 220–240V, 50–60Hz
- Power consumption: (maximum) 700W
- Power consumption: (idle, typical) 90W
- Power consumption: (standby)
- Dimensions: W x D x H 433x325x105mm
- Weight: (net) 10kg
Technical Specifications
- Type
- Power Amplifier
- Technology
- Solid
- Channels
- Stereo
- Power (8Ω)
- 50 watt / channel
- SNR
- 105 dB
Connectivity
- Phono
- No
- Optical
- No
- Coaxial
- No
- USB
- No
- Ethernet
- Yes
- Analog
- Yes
- Headphones
- No
- Subwoofer
- No
- Wifi
- No
- Bluetooth
- No
Features & Functions
- Radio
- No
Dimensions
- Width
- 43.3 cm
- Length
- 32.5 cm
- Height
- 10.5 cm
