The Hager SBN332 three-pole rail switch is designed for mixed resistive and inductive loads and has a utilisation category of AC22A. The LED indicator and green/red mechanical contact indicator show the contact status.
- Number of poles: 3
- Rated voltage: 240/400 V AC
- Rated current: 32 A
- Frequency: 50/60 Hz
- Type: General purpose
- Utilisation category: AC22A
- Load type: Mixed, resistive and inductive
- Protection rating: IP2X with terminal covers
- Status indication: LED indicator and green/red mechanical contact indicator
- Locking: In the ON and OFF positions with the MZN175
- Solid conductor cross-section: 16 mm²
- Flexible conductor cross-section: 10 mm²
Specifications
- Panel Switches Type
- General Use
- Number of Poles
- 3
- Nominal Voltage
- 400 V
- Rated Voltage
- 32 A
Features & Functions
- WiFi
- No
