ATC Audio SCM50ASL Studio Monitor Speakers 9" 50W Pair Brown
Studio Monitor Speakers

ATC Audio SCM50ASL Studio Monitor Speakers 9" 50W Pair Brown

SCM50ASL (Active Speakers)

Drivers:

  • HF 25mm
  • Mid 75mm
  • LF 234mm

Amplitude Linearity: 2dB: 70Hz – 20kHz

Frequency Response -6dB: 38Hz & 25kHz

Harmonized Response: 0.5dB

Dispersion: 80° Horizontal, 10°...

SCM50ASL (Active Speakers)

Drivers:

  • HF 25mm
  • Mid 75mm
  • LF 234mm

Amplitude Linearity: 2dB: 70Hz – 20kHz

Frequency Response -6dB: 38Hz & 25kHz

Harmonized Response: 0.5dB

Dispersion: 80° Horizontal, 10° Vertical

Maximum continuous SPL @1m: 112dB SPL

Crossover Frequency: 380Hz & 3.5kHz

Input Connectivity: XLR

Input Sensitivity: 1V

Input Impedance: >10k ohms...

See full description See full description
24500 00 €
24,50€ cashback in Coins 24,50€ cashback in Coins
Delivery Fri, 11 Sep - Thu, 17 Sep
Free   shipping cost
From SoundGallery
Αθήνα, Αττικής
1 piece
See Speakers on the page of SoundGallery
Review the product
Product report

Description

Description

SCM50ASL (Active Speakers)

Drivers:

  • HF 25mm
  • Mid 75mm
  • LF 234mm

Amplitude Linearity: ±2dB: 70Hz – 20kHz

Frequency Response -6dB: 38Hz & 25kHz

Harmonized Response: ±0.5dB

Dispersion: ±80° Horizontal, ±10° Vertical

Maximum continuous SPL @1m: 112dB SPL

Crossover Frequency: 380Hz & 3.5kHz

Input Connectivity: XLR

Input Sensitivity: 1V

Input Impedance: >10k ohms balanced XLR

Amplifier Output:

  • HF 50 Watts RMS
  • MF 100 Watts RMS
  • LF 200 Watts RMS

Overload Protection: Active FET with instant gain reduction (amplifiers)

Power Requirements:

  • Voltage: 100, 115, 230 (factory set)
  • Frequency: 50/60Hz
  • Capability: Nominal 90 Watts, Driven 350 Watts

Cabinet Dimensions (HxWxD): 717 x 304 x 480mm (including amplifiers, stands add 250mm to height)

Weight: 48.9kg

Available Finishes:

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Technical Specifications

Power (RMS)
50 W
Bass Driver
9 "

Bass Driver

The speaker that handles the low frequencies. It affects the depth, balance, and accuracy of the bass in the mix.
Max SPL
112 dB

Max SPL

The maximum sound level that the monitor can deliver without distortion, important for accurate listening at high volumes.
Driver Configuration
2 No of Drivers

Driver Configuration

The way the monitor divides frequencies among its speakers (e.g. 2-way or 3-way), for more accurate and clear reproduction.

2

The sound frequencies are reproduced by two speakers, a tweeter for the highs and a woofer for the lows.
Tweeter Size
1 "
DSP
No

DSP

Digital signal processing that enhances the sound, automatically adjusts elements such as EQ, filters, or acoustic adaptation according to the space.

Main Specifications

Quantity
Pair
Type
Active

Type

Active: It has a built-in amplifier, you just connect it and it works. It is the most common choice for studio monitors.

Passive: Requires an external amplifier to operate. It offers greater flexibility in setup, but needs additional equipment.
Weight
48.9 kg
Colour
Brown
Connectivity
XLR

Dimensions

Height
71.7 cm
Width
30.4 cm
Length
48 cm

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications
Questions

Questions

Do you have a question about the product?

Those users who have this product can help you

Ask for the product

Description & Specifications

SCM50ASL (Active Speakers)

Drivers:

  • HF 25mm
  • Mid 75mm
  • LF 234mm

Amplitude Linearity: ±2dB: 70Hz – 20kHz

Frequency Response -6dB: 38Hz & 25kHz

Harmonized Response: ±0.5dB

Dispersion: ±80° Horizontal, ±10° Vertical

Maximum continuous SPL @1m: 112dB SPL

Crossover Frequency: 380Hz & 3.5kHz

Input Connectivity: XLR

Input Sensitivity: 1V

Input Impedance: >10k ohms balanced XLR

Amplifier Output:

  • HF 50 Watts RMS
  • MF 100 Watts RMS
  • LF 200 Watts RMS

Overload Protection: Active FET with instant gain reduction (amplifiers)

Power Requirements:

  • Voltage: 100, 115, 230 (factory set)
  • Frequency: 50/60Hz
  • Capability: Nominal 90 Watts, Driven 350 Watts

Cabinet Dimensions (HxWxD): 717 x 304 x 480mm (including amplifiers, stands add 250mm to height)

Weight: 48.9kg

Available Finishes:

Manufacturer

Manufacturer Details

Warnings & Safety Information

Technical Specifications

Power (RMS)
50 W
Bass Driver
9 "

Bass Driver

The speaker that handles the low frequencies. It affects the depth, balance, and accuracy of the bass in the mix.
Max SPL
112 dB

Max SPL

The maximum sound level that the monitor can deliver without distortion, important for accurate listening at high volumes.
Driver Configuration
2 No of Drivers

Driver Configuration

The way the monitor divides frequencies among its speakers (e.g. 2-way or 3-way), for more accurate and clear reproduction.

2

The sound frequencies are reproduced by two speakers, a tweeter for the highs and a woofer for the lows.
Tweeter Size
1 "
DSP
No

DSP

Digital signal processing that enhances the sound, automatically adjusts elements such as EQ, filters, or acoustic adaptation according to the space.

Main Specifications

Quantity
Pair
Type
Active

Type

Active: It has a built-in amplifier, you just connect it and it works. It is the most common choice for studio monitors.

Passive: Requires an external amplifier to operate. It offers greater flexibility in setup, but needs additional equipment.
Weight
48.9 kg
Colour
Brown
Connectivity
XLR

Dimensions

Height
71.7 cm
Width
30.4 cm
Length
48 cm

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
