Product Number

46589

Dimensions

Power Source

Current

Power Source

Current

They connect to a power outlet and provide continuous operation without time limitation.

Provision

Single-Phase

Provision

Single-Phase

Operates with a standard 230V power supply, like a common household socket. Suitable for use in homes, garages, and small workshops.

Noise Level

97 dB

Noise Level: 97

The noise level is noticeable during operation, similar to that of a typical workshop or garage. The intensity level depends on the size and power of the compressor, with larger units producing a louder sound.

Portable

No

Weight

42 kg

Weight: 42

Heavier ones usually require wheels or a fixed position. They can be moved within the same area but not frequently.

Performance

Power

4 hp

Power: 4

Provides power for continuous operation of medium tools. Capable of larger scale painting, more powerful air wrenches, and professional applications.

Maximum Pressure

10 bar

Maximum Pressure: 10

The maximum pressure that can be achieved determines the type of applications and tools that can be used.

Air Delivery

354 lt/min

Air Delivery: 354

Air delivery indicates how many liters of air the compressor can provide per minute. It is a key performance indicator, as it determines how much air is available for operating tools or applications. The higher the air delivery, the more demanding tasks it can support, such as continuous use of an impact wrench, sander, or painting.

Technical Features

Air Chamber

90 lt

Air Chamber: 90

The tank that stores the compressed air. It helps provide a steady supply and allows the compressor not to operate continuously.

Transmission Type

Belt

Transmission Type

Belt

The motion is transferred from the motor to the compressor via a belt, with separate components.

Lubrication

With Oil

Lubrication

With Oil

The mechanism features an oil lubrication system, which distributes oil to the cylinders and pistons during operation. This ensures smooth movement of the parts, reduces wear due to friction, and increases the compressor's lifespan. It requires periodic maintenance and checking of the oil level.
