Maan Corona Bis 60 Sliding Vent Hood 60cm Black
Vent Hoods

Maan Corona Bis 60 Sliding Vent Hood 60cm Black

Key features:

  • Aluminum filter (washable)
  • Speeds: 3
  • Noise Level: 48/68 dB
  • Maximum suction power: 635 m³/h

The Maan vent hood with a suction power of 635 m³/h, which can adequately cover areas up to 22m².

See full description

  • Item

    Retractable

    It is placed in a cabinet and only the part of the extractor containing the filters is pulled out.

  • Noise Level

    Shows how much noise the extractor makes when it is in operation.

    2. The fewer the db, the quieter it is. An extractor with 58db or less is considered quite quiet.

  • Energy class

    The energy class categorizes devices into groups according to the current they consume, ranging from the lowest D to the highest A+++.

    2. The higher the energy class, the lower the electricity consumption.

    3. For example, for a 12 sq.m. kitchen with an extractor fan that has an absorption power of about 340m³/h and frequent weekly use, the difference in annual cost from D to A is about €6, and from A to A+++ the difference is almost negligible.

  • Extraction Power (Max)

    Displays the maximum absorption capacity. To calculate the required absorbency, knowledge of the dimensions of the kitchen space is necessary.


    For example, for a 7 sqm kitchen, the required absorption power is approximately 200m³/h, for 12 sqm it is approximately 340m³/h, and for 15 sqm it is 420m³/h and above.

  • Filter Type

    Charcoal (optional)

    Carbon filters are used when range hoods operate without a duct connection and the air is recirculated into the room.


    They are not washable and it is recommended to replace them every 4 months.


    Their use reduces the efficiency of the range hood by about 30%.
  • See all
This product is temporarily unavailable at Skroutz Last updated: 15 days ago
Product report

Description

Description

The Maan company's vent hood is installed in a cabinet, and only the part of the hood containing the filters slides out.

The maximum suction power is 635 m³/h, which can adequately cover spaces up to 22 square meters (with a height of 2.85 meters).

The air drawn in by the vent hood is either expelled through a duct or recirculated within the hood. For operation with air extraction, a duct needs to be installed to vent the air outside the kitchen. It accepts carbon filters, which are necessary for operation with air recirculation. The carbon filters are not washable and it is recommended to replace them every 4-6 months.

Specifications

  • Color: Black
  • Light: 1 x 10 W
  • Material: Steel, Tempered glass
  • Control: Mechanical
  • Lighting location: Rear
  • Filter: Aluminum (washable)
  • with Motor
  • Maximum extraction rate: 635 m³/h
  • Noise level (low speed): 48 dB
  • Noise level (maximum speed): 68 dB
  • Number of speeds: 3
  • Energy efficiency class (old): B
  • Lighting class: B
  • Annual energy consumption: 53 kWh
  • Energy efficiency class: A+++ to D
  • Fluid dynamic efficiency class: B

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Product Details

Type
Retractable

Type

Retractable
It is placed in a cabinet and only the part of the extractor containing the filters is pulled out.
Retro
No
Grease Filter Material
Charcoal (optional)

Grease Filter Material

Charcoal (optional)

Carbon filters are used when range hoods operate without a duct connection and the air is recirculated into the room.


They are not washable and it is recommended to replace them every 4 months.


Their use reduces the efficiency of the range hood by about 30%.
Extraction Mode
Extraction or Recirculation

Extraction Mode

Concerns the way in which the extractor absorbs air.

Extraction or Recirculation

The extractor fan has both functions. The air that the extractor fan draws can either be extracted through a pipe or recycled back into the fan. For air extraction function, a pipe is needed to remove the air outside the kitchen.
Dual Motor
No
Type of Control
Switches
Timer Function
No
Filter Cleaning Indicator
No
Washable Filter
Yes
Colour
Black

Technical Features

Extraction Power (Max)
635 m³/h

Extraction Power (Max)

Displays the maximum absorption capacity. To calculate the required absorbency, knowledge of the dimensions of the kitchen space is necessary.


For example, for a 7 sqm kitchen, the required absorption power is approximately 200m³/h, for 12 sqm it is approximately 340m³/h, and for 15 sqm it is 420m³/h and above.

Dimensions

Width
60 cm

Energy Label

Energy Class
B

Energy Class

The energy class categorizes devices into groups according to the current they consume, ranging from the lowest D to the highest A+++.

2. The higher the energy class, the lower the electricity consumption.

3. For example, for a 12 sq.m. kitchen with an extractor fan that has an absorption power of about 340m³/h and frequent weekly use, the difference in annual cost from D to A is about €6, and from A to A+++ the difference is almost negligible.
Average Energy Consumption per Year
53 kWh/y
Extraction Flow Efficiency
B

Extraction Flow Efficiency

Expresses how effective the extractor is in absorbing odors. 2. The performance scale starts at G for less efficient extractors and goes up to A for more efficient ones. 3. Typically, a rating of D and above is a good performance for effectively absorbing odors from cooking.
Lighting Efficiency
B

Lighting Efficiency

Expresses the intensity of the hood's lighting. The scale starts from G for the lowest performance where the lighting is quite soft, up to A for the highest performance where the lighting is more intense. It is usually recommended to have a lighting performance index of C or higher to facilitate cooking with more intense lighting.
Fat Retention Efficiency
D

Fat Retention Efficiency

Shows how effectively the filters of the extractor work in retaining fat.


The scale starts from G for the lowest performance, up to A for the highest performance.


A performance rating of C and above is considered satisfactory for fat retention during cooking.
Noise Level
68 dB

Noise Level

Shows how much noise the extractor makes when it is in operation.

2. The fewer the db, the quieter it is. An extractor with 58db or less is considered quite quiet.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Reviews (6)

Reviews

3.8
6
3.8
Review this product
  1. 3
  2. 1
  3. 1
  4. 2 stars
    0
  5. 1
Review this product
  • Is its lighting satisfactory?
  • Performance
  • Construction quality
  • Value for money
  • Noisy
Questions (2)

Questions

62 users have this product and can help you

Ask for the product
aroykos81

Τα φίλτρα άνθρακα μπαίνουν εσωτερικά (γυρίζοντας κουμπωτά) αριστερά και δεξιά του μοτερ. Το φως δεν ανάβει ανοίγωντας το συρώμενο, αλλά με διακόπτη.

aroykos81 2024-08-26
Verified purchase
1 Reply Reply to
leonidas_r

υπάρχουν συμβατά φίλτρα αλουμινίου στην ελληνική αγορά ;

leonidas_r 2024-12-29
1 Reply Reply to
See all questions (2)

Description & Specifications

The Maan company's vent hood is installed in a cabinet, and only the part of the hood containing the filters slides out.

The maximum suction power is 635 m³/h, which can adequately cover spaces up to 22 square meters (with a height of 2.85 meters).

The air drawn in by the vent hood is either expelled through a duct or recirculated within the hood. For operation with air extraction, a duct needs to be installed to vent the air outside the kitchen. It accepts carbon filters, which are necessary for operation with air recirculation. The carbon filters are not washable and it is recommended to replace them every 4-6 months.

Specifications

  • Color: Black
  • Light: 1 x 10 W
  • Material: Steel, Tempered glass
  • Control: Mechanical
  • Lighting location: Rear
  • Filter: Aluminum (washable)
  • with Motor
  • Maximum extraction rate: 635 m³/h
  • Noise level (low speed): 48 dB
  • Noise level (maximum speed): 68 dB
  • Number of speeds: 3
  • Energy efficiency class (old): B
  • Lighting class: B
  • Annual energy consumption: 53 kWh
  • Energy efficiency class: A+++ to D
  • Fluid dynamic efficiency class: B

Manufacturer

Manufacturer Details

Warnings & Safety Information

Product Details

Type
Retractable

Type

Retractable
It is placed in a cabinet and only the part of the extractor containing the filters is pulled out.
Retro
No
Grease Filter Material
Charcoal (optional)

Grease Filter Material

Charcoal (optional)

Carbon filters are used when range hoods operate without a duct connection and the air is recirculated into the room.


They are not washable and it is recommended to replace them every 4 months.


Their use reduces the efficiency of the range hood by about 30%.
Extraction Mode
Extraction or Recirculation

Extraction Mode

Concerns the way in which the extractor absorbs air.

Extraction or Recirculation

The extractor fan has both functions. The air that the extractor fan draws can either be extracted through a pipe or recycled back into the fan. For air extraction function, a pipe is needed to remove the air outside the kitchen.
Dual Motor
No
Type of Control
Switches
Timer Function
No
Filter Cleaning Indicator
No
Washable Filter
Yes
Colour
Black

Technical Features

Extraction Power (Max)
635 m³/h

Extraction Power (Max)

Displays the maximum absorption capacity. To calculate the required absorbency, knowledge of the dimensions of the kitchen space is necessary.


For example, for a 7 sqm kitchen, the required absorption power is approximately 200m³/h, for 12 sqm it is approximately 340m³/h, and for 15 sqm it is 420m³/h and above.

Dimensions

Width
60 cm

Energy Label

Energy Class
B

Energy Class

The energy class categorizes devices into groups according to the current they consume, ranging from the lowest D to the highest A+++.

2. The higher the energy class, the lower the electricity consumption.

3. For example, for a 12 sq.m. kitchen with an extractor fan that has an absorption power of about 340m³/h and frequent weekly use, the difference in annual cost from D to A is about €6, and from A to A+++ the difference is almost negligible.
Average Energy Consumption per Year
53 kWh/y
Extraction Flow Efficiency
B

Extraction Flow Efficiency

Expresses how effective the extractor is in absorbing odors. 2. The performance scale starts at G for less efficient extractors and goes up to A for more efficient ones. 3. Typically, a rating of D and above is a good performance for effectively absorbing odors from cooking.
Lighting Efficiency
B

Lighting Efficiency

Expresses the intensity of the hood's lighting. The scale starts from G for the lowest performance where the lighting is quite soft, up to A for the highest performance where the lighting is more intense. It is usually recommended to have a lighting performance index of C or higher to facilitate cooking with more intense lighting.
Fat Retention Efficiency
D

Fat Retention Efficiency

Shows how effectively the filters of the extractor work in retaining fat.


The scale starts from G for the lowest performance, up to A for the highest performance.


A performance rating of C and above is considered satisfactory for fat retention during cooking.
Noise Level
68 dB

Noise Level

Shows how much noise the extractor makes when it is in operation.

2. The fewer the db, the quieter it is. An extractor with 58db or less is considered quite quiet.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
