Pedrollo VXC 40/65 Three-phase Pump Waste Water / Sewage 4hp 48SGV9864A
Submersible Water Pumps

Pedrollo VXC 40/65 Three-phase Pump Waste Water / Sewage 4hp 48SGV9864A

The pump is made of heavy-duty cast iron, ensuring absolute stability and resistance to wear. It is suitable for sewage with particles and sludge, as well as liquids with bubbles.

  • Type: VXC 40/65
  • ...

The pump is made of heavy-duty cast iron, ensuring absolute stability and resistance to wear. It is suitable for sewage with particles and sludge, as well as liquids with bubbles.

  • Type: VXC 40/65
  • Pump Type: Vortex
  • Power Supply: Electric Current
  • Motor Power: 4 Hp
  • Power: 4Hp-3000Watt
  • Voltage: 380 Volt/50 Hz
  • Absorption: 6.20 A
  • Usage: Sewage
  • Discharge Outlet: Φ...
See full description See full description

Top specs

  • Horsepower

    Horsepower indicates the kinetic power of the pump. Higher horsepower means more efficiency in water pumping, affecting the flow (l/h) and the head (m).

  • Voltage

    Three-Phase

    It is mainly used for pumps and other industrial devices that require greater power or higher efficiency. Three-phase power supply is ideal for large installations or applications with increased energy demands.

  • Power

    It is the energy consumed by the motor to pump water. The greater the power, the more effectively it can lift and move water, especially over long distances or heights.

  • Manometric Height

    5.5

    The Maximum Head Height refers to the maximum height at which the pump can lift water against resistance (such as pipes or filters). As the head height increases, the pump's flow rate decreases.

    • The maximum head height is considered by manufacturers to be the point where the water will just barely reach.
    • The maximum performance is considered by manufacturers to be the water flow at 0-1 meter head height.
  • See all
1.250,00 €
1059 80 €
-15%
price drop
1,06€ cashback in Coins 1,06€ cashback in Coins
Delivery up to 10 days
18,80 €

Reduced Shipping

For purchases from Skroutz a discount is applied for this particular product.

Learn more
Delivery to your floor available
Do you want it with Free shipping?
From jadevertools
ΕΧΕΔΩΡΟΥ, Θεσσαλονίκης
20+ pieces
See Water Pumps on the page of jadevertools
What if it breaks?

You're covered by the statutory 2-year warranty. Contact us and we'll handle the entire process with the store, ensuring your issue is resolved with prompt support through a repair, replacement, or refund.

What if I change my mind?

No problem, as long as it's within 14 days. We'll come and pick it up (completely free of charge if you have Skroutz Plus) and refund your money.

Review the product
Product report

Description

Description

The pump is made of heavy-duty cast iron, ensuring absolute stability and resistance to wear. It is suitable for sewage with particles and sludge, as well as liquids with bubbles.

  • Type: VXC 40/65
  • Pump Type: Vortex
  • Power Supply: Electric Current
  • Motor Power: 4 Hp
  • Power: 4Hp-3000Watt
  • Voltage: 380 Volt/50 Hz
  • Absorption: 6.20 A
  • Usage: Sewage
  • Discharge Outlet: Φ 3"-80mm
  • Max Performance: 15.50 M
  • Max Flow Rate: 72.00 m3/h
  • Body Material: Cast Iron
  • Impeller Material: Stainless Steel AISI 304
  • Pumped Liquid Temperature: 40 °C
  • Solid Passage: Φ 65 mm
  • Maximum Submersion Depth: 10 M
  • Cable Length: 10 M
  • Float: No
  • Additional Features: They have a double sealing
  • Net Weight: 50.00 Kg
  • Product Length: 36.00 cm
  • Product Width: 24.00 cm
  • Product Height: 54.70 cm

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Dimensions

Type
Waste Water / Sewage

Type

Waste Water / Sewage

Waste water / sewage pumps are used for pumping and transporting waste water, sewage, and other liquids containing solids or particles
Power Source
Electric

Power Source

Electric
The power supply refers to the pump's need for electrical energy from an external power source, such as single-phase or three-phase power.
Voltage
Three-Phase

Voltage

Three-Phase

It is mainly used for pumps and other industrial devices that require greater power or higher efficiency. Three-phase power supply is ideal for large installations or applications with increased energy demands.
Horsepower
4 hp

Horsepower

Horsepower indicates the kinetic power of the pump. Higher horsepower means more efficiency in water pumping, affecting the flow (l/h) and the head (m).
Power
3000 W

Power

It is the energy consumed by the motor to pump water. The greater the power, the more effectively it can lift and move water, especially over long distances or heights.
Cable Length
10 m

Features

Electronic Level Sensor
No

Electronic Level Sensor

It automatically activates the pump without the classic hanging float switch. It is ideal for narrow spaces and pits, as there is no risk of it getting stuck anywhere and flooding the area.
with Cutter Impeller
No

with Cutter Impeller

Components that chop, "cut" solid materials, such as organic waste or other particles, before they pass into the pump. They are mainly used in sewage or dirty water pumps, preventing clogging or damage to the system.
Float switch
Yes

Float switch

It is a mechanism that automatically controls the operation of the pump. When the water level reaches a predetermined height, the float activates the pump.
Vortex
Yes

Vortex

The vortex system in submersible water pumps uses vortex technology to create a rotating water current, which helps in the efficient transfer of water, even when it contains particles or solids.

Pumping Specifications

Maximum Head Height
5.5 m

Maximum Head Height: 5.5


The Maximum Head Height refers to the maximum height at which the pump can lift water against resistance (such as pipes or filters). As the head height increases, the pump's flow rate decreases.

  • The maximum head height is considered by manufacturers to be the point where the water will just barely reach.
  • The maximum performance is considered by manufacturers to be the water flow at 0-1 meter head height.
Maximum Output
72 m³/h

Maximum Output

The maximum output or flow of a submersible water pump, as defined by the manufacturers, is the maximum amount of water the pump can move under ideal conditions, usually with zero head (i.e., no lift resistance).
Pump Submersion Depth
10 m
Maximum Particle Size
65 mm

Maximum Particle Size

Specifies the largest size of solid particles (such as sand, stones, or other impurities) that the device can pump without clogging or being damaged.
Shallow Suction
No

Shallow Suction

This function allows the pump to suck water from an extremely low level (up to 1-3 mm), ideal for flooded floors and basements.

Materials & Construction

Set
No
Stainless
Yes

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
