Phase Relays

Maxge Phase 4-Pole Earth Leakage Relay 63A

  • Rail-mounted residual current circuit breaker, four-pole (4P) Type A
  • Specifications: EN/IEC 60898-1A
  • Protection: Leakage current and short circuit
  • Width: 18mm per pole
  • Mounting:
  • Rail-mounted residual current circuit breaker, four-pole (4P) Type A
  • Specifications: EN/IEC 60898-1A
  • Protection: Leakage current and short circuit
  • Width: 18mm per pole
  • Mounting: 35mm DIN rail
  • Number of poles: 4P (3+N)
  • Rated current: 63A
See full description See full description
27 20
28 Coins 28 Coins
Delivery by Mon, 07 Sep
2,50 € to a Skroutz Point
Do you want it with Free shipping?
From Emimikos 4.8 (37)
Λιβαδειά, Βοιωτίας
In-store pickup available
See Electrical Panel Supplies on the page of Emimikos
What if it breaks?

You're covered by the statutory 2-year warranty. Contact us and we'll handle the entire process with the store, ensuring your issue is resolved with prompt support through a repair, replacement, or refund.

What if I change my mind?

No problem, as long as it's within 14 days. We'll come pick it up or you can choose the Skroutz Point that suits you, completely free for up to 2 times per year, and we'll refund your money. Get Skroutz Plus to enjoy unlimited free returns.

Description

Description

  • Rail-mounted residual current circuit breaker, four-pole (4P) Type A
  • Specifications: EN/IEC 60898-1A
  • Protection: Leakage current and short circuit
  • Width: 18mm per pole
  • Mounting: 35mm DIN rail
  • Number of poles: 4P (3+N)
  • Rated current: 63A
  • Rated voltage: 415VAC, 50/60Hz
  • Rated residual current IΔn: 30mA
  • Rated short-circuit current: 630A
  • Tripping time: <0.1s
  • Terminal capacity: up to 25mm²

Manufacturer

See full description

Specifications

Specifications

Type
Earth Leakage
Number of Poles
4
Nominal Voltage
63 A
Leakage Current
30 mA
with Energy Consumption Meter
No
with Timer
No
Type of Residual Current Relay
Type A

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications
Questions

Questions

Do you have a question about the product?

4 users have this product and can help you

Ask for the product

Description & Specifications

  • Rail-mounted residual current circuit breaker, four-pole (4P) Type A
  • Specifications: EN/IEC 60898-1A
  • Protection: Leakage current and short circuit
  • Width: 18mm per pole
  • Mounting: 35mm DIN rail
  • Number of poles: 4P (3+N)
  • Rated current: 63A
  • Rated voltage: 415VAC, 50/60Hz
  • Rated residual current IΔn: 30mA
  • Rated short-circuit current: 630A
  • Tripping time: <0.1s
  • Terminal capacity: up to 25mm²

Manufacturer

Type
Earth Leakage
Number of Poles
4
Nominal Voltage
63 A
Leakage Current
30 mA
with Energy Consumption Meter
No
with Timer
No
Type of Residual Current Relay
Type A

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
