Kraft 4SD10/24 Three-phase Pump Drilling 5.5hp 63566
Submersible Water Pumps

Kraft 4SD10/24 Three-phase Pump Drilling 5.5hp 63566

Key features:

  • Maximum pump immersion 80m
  • Maximum water temperature +35°C
  • Outlet: 2’’
  • Maximum flow rate: 12.6m³/h
See full description

Top specs

  • Horsepower

    Horsepower indicates the kinetic power of the pump. Higher horsepower means more efficiency in water pumping, affecting the flow (l/h) and the head (m).

  • Voltage

    Three-Phase

    It is mainly used for pumps and other industrial devices that require greater power or higher efficiency. Three-phase power supply is ideal for large installations or applications with increased energy demands.

  • Power

    It is the energy consumed by the motor to pump water. The greater the power, the more effectively it can lift and move water, especially over long distances or heights.

  • Manometric Height

    162

    The Maximum Head Height refers to the maximum height at which the pump can lift water against resistance (such as pipes or filters). As the head height increases, the pump's flow rate decreases.

    • The maximum head height is considered by manufacturers to be the point where the water will just barely reach.
    • The maximum performance is considered by manufacturers to be the water flow at 0-1 meter head height.
  • See all
314 17 €
315 Coins 315 Coins
Delivery by Fri, 14 Aug
18,00 €

Reduced Shipping

For purchases from Skroutz a discount is applied for this particular product.

Learn more
Delivery to your floor available
Do you want it with 13,00 € shipping?
From Getters 4.5 (110)
4.5 (110 reviews)
Αχαρνές, Αττικής
In-store pickup available
10 pieces
See Water Pumps on the page of Getters
What if it breaks?

You're covered by the statutory 2-year warranty. Contact us and we'll handle the entire process with the store, ensuring your issue is resolved with prompt support through a repair, replacement, or refund.

What if I change my mind?

No problem, as long as it's within 14 days. We'll come and pick it up (completely free of charge if you have Skroutz Plus) and refund your money.

Product report

Description

Description

Submersible borehole pump from the manufacturer Kraft, used for pumping water from depths greater than 8 meters.

Features

  • Suitable for pumping water from wells or tanks, for residential and professional use
  • Minimum well diameter 4”
  • Maximum water temperature +35°C
  • Maximum water sand content 0.25%
  • Maximum pump submersion 80m
  • The pump construction complies with NEMA standards, featuring a pump body and shaft made of stainless steel, impellers and separators made of PPO, and an oil-lubricated motor.
  • Comes with an ON-OFF control panel that includes a capacitor, thermal protector, and one meter cable with male Schuko plug.

Specifications

  • Maximum pump submersion 80m
  • Maximum water temperature +35°C
  • Output: 64000Lit/h
  • Minimum well diameter: 4" (100 mm)
  • Maximum water temperature: +35ºC
  • Maximum sand content: 0.25%.
  • Outlet: 2’’
  • Maximum pump submersion: 100m
  • Electric motor power: 5.5Hp
  • Voltage: 400V
  • Maximum head: 162m
  • Pump height: 1878mm
  • Dimensions: 100x110x1300 + 100x130x750 mm
  • Weight (N/G): 34.2 / 35.9 kg

For the operation of the pump, the use of an electronic control panel (63590 / 63591) is required

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Dimensions

Type
Drilling

Type

Drilling
Drilling pumps are used for pumping water or other liquids from underground boreholes (water sources) to surfaces for various purposes, such as water supply, irrigation, industrial applications
Power Source
Electric

Power Source

Electric
The power supply refers to the pump's need for electrical energy from an external power source, such as single-phase or three-phase power.
Voltage
Three-Phase

Voltage

Three-Phase

It is mainly used for pumps and other industrial devices that require greater power or higher efficiency. Three-phase power supply is ideal for large installations or applications with increased energy demands.
Horsepower
5.5 hp

Horsepower

Horsepower indicates the kinetic power of the pump. Higher horsepower means more efficiency in water pumping, affecting the flow (l/h) and the head (m).
Power
4125 W

Power

It is the energy consumed by the motor to pump water. The greater the power, the more effectively it can lift and move water, especially over long distances or heights.

Features

Electronic Level Sensor
No

Electronic Level Sensor

It automatically activates the pump without the classic hanging float switch. It is ideal for narrow spaces and pits, as there is no risk of it getting stuck anywhere and flooding the area.
with Cutter Impeller
No

with Cutter Impeller

Components that chop, "cut" solid materials, such as organic waste or other particles, before they pass into the pump. They are mainly used in sewage or dirty water pumps, preventing clogging or damage to the system.
Float switch
No

Float switch

It is a mechanism that automatically controls the operation of the pump. When the water level reaches a predetermined height, the float activates the pump.
Outlet Nozzle
2"

Outlet Nozzle

The outlet nozzle refers to the point or the external diameter of the pump from which the pumped water or liquid exits. It is an important feature for determining the connection of the pump with the piping system and affects the flow capacity of the liquid.
Vortex
No

Vortex

The vortex system in submersible water pumps uses vortex technology to create a rotating water current, which helps in the efficient transfer of water, even when it contains particles or solids.

Pumping Specifications

Maximum Head Height
162 m

Maximum Head Height: 162


The Maximum Head Height refers to the maximum height at which the pump can lift water against resistance (such as pipes or filters). As the head height increases, the pump's flow rate decreases.

  • The maximum head height is considered by manufacturers to be the point where the water will just barely reach.
  • The maximum performance is considered by manufacturers to be the water flow at 0-1 meter head height.
Maximum Output
12.6 m³/h

Maximum Output

The maximum output or flow of a submersible water pump, as defined by the manufacturers, is the maximum amount of water the pump can move under ideal conditions, usually with zero head (i.e., no lift resistance).
Pump Submersion Depth
80 m
Shallow Suction
No

Shallow Suction

This function allows the pump to suck water from an extremely low level (up to 1-3 mm), ideal for flooded floors and basements.

Materials & Construction

Set
No
Stainless
No

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Reviews (1)

Reviews

5.0
1
5.0
Review this product
  1. 1
  2. 4 stars
    0
  3. 3 stars
    0
  4. 2 stars
    0
  5. 1 star
    0
Review this product
  • Takis_Christ
    5
    7 out of 7 members found this review helpful
    Takis_Christ

    One and a half year now, 10 hours a day, 10 meters in the water and 90 meters in height, 5 cubic meters of water per hour, the star has come out

    Translated from Greek ·
    Did you find this review helpful?
  • Takis_Christ
    5
    Takis_Christ

    One and a half year now, 10 hours a day, 10 meters in the water and 90 meters in height, 5 cubic meters of water per hour, the star has come out

    Translated from Greek ·
    7
  • See all
Questions (1)

Questions

3 users have this product and can help you

Ask for the product
mixaminas2009

εχει μετρησει καποιος ποσα κυβικα βγαζει την ωρα και στα ποσα μετρα?

mixaminas2009 2026-02-01
0 Replies Reply to
See all questions (1)

Description & Specifications

Submersible borehole pump from the manufacturer Kraft, used for pumping water from depths greater than 8 meters.

Features

  • Suitable for pumping water from wells or tanks, for residential and professional use
  • Minimum well diameter 4”
  • Maximum water temperature +35°C
  • Maximum water sand content 0.25%
  • Maximum pump submersion 80m
  • The pump construction complies with NEMA standards, featuring a pump body and shaft made of stainless steel, impellers and separators made of PPO, and an oil-lubricated motor.
  • Comes with an ON-OFF control panel that includes a capacitor, thermal protector, and one meter cable with male Schuko plug.

Specifications

  • Maximum pump submersion 80m
  • Maximum water temperature +35°C
  • Output: 64000Lit/h
  • Minimum well diameter: 4" (100 mm)
  • Maximum water temperature: +35ºC
  • Maximum sand content: 0.25%.
  • Outlet: 2’’
  • Maximum pump submersion: 100m
  • Electric motor power: 5.5Hp
  • Voltage: 400V
  • Maximum head: 162m
  • Pump height: 1878mm
  • Dimensions: 100x110x1300 + 100x130x750 mm
  • Weight (N/G): 34.2 / 35.9 kg

For the operation of the pump, the use of an electronic control panel (63590 / 63591) is required
