Automatic circuit breaker type S204M-K40, DIN rail, 4 poles with screw terminals, 4 poles, curve K, for the protection of motors, transformers, and auxiliary circuits against overloads and short circuits. Suitable for residential, commercial, and industrial installations with loads that have high starting current.
- Standards: IEC/EN 60898-1, IEC/EN 60947-2
- Safety terminals with double chamber
- Independent chamber for busbar and cable installation
- Permanent laser-printed markings and labels
- Screws that do not come out of the body
- Loss protection
- Wide range of accessories
- Rated values: 40A, 400/440V AC, 50Hz
- Short-circuit breaking capacity: 10kA
- Protection degree: IP20, cover: IP40
- On/off indicators: red-green
- Color: light gray (RAL 7035)
S200M series from ABB.
Specifications
- Number of Poles
- 4
- Rated Current
- 40 A
- Operating Curve
- Curve K
Power Supply
- AC
- Yes
- DC
- No
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
