Aruba AP-503 (RW) Access Point Wi‑Fi 6 Dual Band (2.4 & 5GHz)
Access Points

Aruba AP-503 (RW) Access Point Wi‑Fi 6 Dual Band (2.4 & 5GHz)

The Aruba AP-503 (RW) access point provides dual-band Wi‑Fi 6 connectivity at 2.4 GHz and 5 GHz, with 2x2 MIMO technology. It is suitable for indoor use and features one RJ‑45 Ethernet port with LAN...

The Aruba AP-503 (RW) access point provides dual-band Wi‑Fi 6 connectivity at 2.4 GHz and 5 GHz, with 2x2 MIMO technology. It is suitable for indoor use and features one RJ‑45 Ethernet port with LAN speeds of up to 1000 Mbps, as well as PoE support.

The built-in omnidirectional antenna offers a gain of up to 1.7 dBi in the 2.4 GHz band and up to 4.8 dBi in...

See full description See full description

Top specs

  • Maximum WLAN Speed

    Theoretical maximum speed with one wirelessly connected device, mainly used for marketing purposes. The speed that each connected device will have depends on the distance, obstacles, how many other devices are connected, how many other networks exist in the same area, etc.

  • Ethernet Ports

    Wired connection capability through an Ethernet network port. It allows connection via Ethernet cable, ensuring a stable and reliable connection, high data transfer speeds, and reduced interference compared to Wi-Fi.

  • Frequency

    The frequencies at which the Access Point can transmit.
    2. Additional frequencies allow for greater speed on more devices.

    Dual Band (2.4 & 5GHz)

    They transmit signals on two frequencies. They offer higher speeds compared to single and connect more devices. The 2.4Ghz frequency is the most common and, as it has a large range, is usually congested by neighboring Wi-Fi signals, making communication between devices more difficult. The 5Ghz provides higher speeds than the 2.4Ghz but is more sensitive to obstacles (e.g. walls) that reduce its range. This difference, as well as its more limited use, helps to have fewer interferences from other networks.

  • Wi-Fi Generation

    Wi‑Fi 6

    The most advanced Wi-Fi standard, offering speeds up to 40% faster than Wi-Fi 5, coordinates communication with connected devices to consume less battery, and works better in environments with many Wi-Fi devices.

    Ideal for homes with many smart devices.

    Compatible with all previous generations.
  • See all
309 00 €
You earn a 20,00 € coupon
for your next purchase

Deals & Benefits

Κέρδισε 20€ κουπόνι με Mastercard

Τα Mastercard Wednesdays είναι εδώ. Κάνε σήμερα μία παραγγελία άνω των 200€ με κάρτα Mastercard* και κέρδισε 20€ κουπόνι για την επόμενη παραγγελία σου άνω των 150€!

Μην ξεχνάς, μπορείς να κερδίσεις έως 2 κουπόνια συνολικής αξίας 30€!

Η προσφορά ισχύει μέχρι τα μεσάνυχτα γι' αυτό βιάσου.

*Εξαιρούνται παραγγελίες μέσω Revolut Pay & Klarna

Terms & conditions apply
You earn a 25,00 € coupon
for your next purchase

Deals & Benefits

Κέρδισε 25€ κουπόνι με Mastercard

Τα Mastercard Wednesdays είναι εδώ. Κάνε σήμερα μία παραγγελία άνω των 200€ με κάρτα Mastercard* και κέρδισε 25€ κουπόνι για την επόμενη παραγγελία σου άνω των 150€!

Μην ξεχνάς, μπορείς να κερδίσεις έως 2 κουπόνια συνολικής αξίας 40€!

Η προσφορά ισχύει μέχρι τα μεσάνυχτα γι' αυτό βιάσου.

*Εξαιρούνται παραγγελίες μέσω Revolut Pay & Klarna

Terms & conditions apply
Delivery by Tue, 10 Nov
Free   shipping cost
From Allaboutoffice 4.8 (42)
4.8 (42 reviews)
Κόρινθος, Κορινθίας
In-store pickup available
See Networking on the page of Allaboutoffice

Shop selection criteria

Why do we recommend buying from this shop?

We don’t only look at the price. We weigh different factors to find an offer that combines a good price, fast delivery and a reliable purchase.

  • Product price

    We calculate the total price you will pay and any discounts available from the shop.

  • Shipping & delivery time

    We check how quickly the product can be shipped and when you will receive it, based on your address.

  • Shop reliability

    We look at how often shops complete their orders successfully and how consistently they serve their customers.

  • Official reseller

    Where available, we take into account whether the shop is an official reseller of the brand.
What if it breaks?

You're covered by the statutory 2-year warranty. Contact us and we'll handle the entire process with the store, ensuring your issue is resolved with prompt support through a repair, replacement, or refund.

What if I change my mind?

No problem, as long as it's within 14 days. We'll come pick it up or you can choose the Skroutz Point that suits you, completely free for up to 2 times per year, and we'll refund your money. Get Skroutz Plus to enjoy unlimited free returns.

You can select additional services after adding the product to the cart.
Review the product
Product report

Description

Description

The Aruba AP-503 (RW) access point provides dual-band Wi‑Fi 6 connectivity at 2.4 GHz and 5 GHz, with 2x2 MIMO technology. It is suitable for indoor use and features one RJ‑45 Ethernet port with LAN speeds of up to 1000 Mbps, as well as PoE support.

The built-in omnidirectional antenna offers a gain of up to 1.7 dBi in the 2.4 GHz band and up to 4.8 dBi in the 5 GHz band. WPA, WPA2 and WPA3 are supported. The access point also features a TPM module, a reset button, and LED indicators for reset, status and system.

  • Wi‑Fi generation: Wi‑Fi 6
  • Networking standards: IEEE 802.11a, 802.11b/g/n, 802.11ac, 802.11ax
  • Frequency: Dual-band 2.4 GHz and 5 GHz
  • Maximum WLAN speed: 1467 Mbps
  • MIMO technology: 2x2
  • Antenna type: Built-in omnidirectional
  • Maximum antenna gain: 1.7 dBi at 2.4 GHz and 4.8 dBi at 5 GHz
  • Ethernet ports: 1 RJ‑45
  • LAN speed: 1000 Mbps
  • USB ports: 1 USB Type‑A
  • USB version: USB 2.0
  • PoE support: Yes
  • Security: WPA, WPA2 and WPA3
  • Features: TPM module, reset button and LED indicators
  • Mounting: Indoor
  • Weight: 255 g
  • Dimensions: 145 x 145 x 35 mm
  • Operating temperature: 0–40 °C
  • Storage temperature: −25–55 °C
  • Operating relative humidity: 10–100%
  • Relative humidity range: 5–95%
  • Certification: Low Voltage Directive (LVD)
  • Packaging: Single kit

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Technical Specifications

Frequency
Dual Band (2.4 & 5GHz)

Frequency

The frequencies at which the Access Point can transmit.
2. Additional frequencies allow for greater speed on more devices.

Dual Band (2.4 & 5GHz)
They transmit signals on two frequencies. They offer higher speeds compared to single and connect more devices. The 2.4Ghz frequency is the most common and, as it has a large range, is usually congested by neighboring Wi-Fi signals, making communication between devices more difficult. The 5Ghz provides higher speeds than the 2.4Ghz but is more sensitive to obstacles (e.g. walls) that reduce its range. This difference, as well as its more limited use, helps to have fewer interferences from other networks.
Maximum WLAN Speed
1467 Mbps

Maximum WLAN Speed

Theoretical maximum speed with one wirelessly connected device, mainly used for marketing purposes. The speed that each connected device will have depends on the distance, obstacles, how many other devices are connected, how many other networks exist in the same area, etc.
Wi-Fi Generation
Wi‑Fi 6

Wi-Fi Generation

Wi‑Fi 6

The most advanced Wi-Fi standard, offering speeds up to 40% faster than Wi-Fi 5, coordinates communication with connected devices to consume less battery, and works better in environments with many Wi-Fi devices.

Ideal for homes with many smart devices.

Compatible with all previous generations.
IEEE Networking Standards
802.11a, 802.11 b/g/n, 802.11ac, 802.11ax
LAN speed
1000 Mbps
Wi-Fi Mesh Network
No

Wi-Fi Mesh Network

Technology that allows the creation of a unified, flexible network where multiple Access Points work together to provide broader and more stable Wi-Fi coverage. Ideal for large homes, offices, and businesses.
Ethernet Backhaul
No

Ethernet Backhaul

The wired connection between access points using an Ethernet cable, so that their communication does not burden the wireless network. It offers greater stability, higher speeds, and better coverage compared to wireless backhaul.
Antenna Power (max)
4.8 dBi

Antenna Power (max)

Indicates how "directional" the antenna's signal is. A higher value means greater range in a specific direction, while a lower value offers more uniform coverage around the device.
PoE Support
PoE

PoE Support

PoE
Device powered through the network cable, without a separate power adapter. Offers simple installation with a single cable.
MIMO Technology
2x2

MIMO Technology

Technology that uses multiple antennas for simultaneous sending and receiving of data. This improves the speed and stability of Wi-Fi, especially when there are many connected devices.

General Characteristics

Placement
Indoor
Ethernet Ports
1

Ethernet Ports

Wired connection capability through an Ethernet network port. It allows connection via Ethernet cable, ensuring a stable and reliable connection, high data transfer speeds, and reduced interference compared to Wi-Fi.
USB
USB 2.0

USB

Allows the connection of external devices, such as USB flash drives, external hard drives, or printers. It is mainly used for file sharing and media streaming within the network, offering flexibility and additional functions in the wireless environment.
Packaging
Single Kit

Installation Type

Ceiling
No

Ceiling

Ceiling installation for uniform coverage of the area from above. Ideal for offices, shops, and professional spaces.
Wall
No

Wall

Wall mounting for targeted coverage of specific areas or rooms. Suitable for more flexible installations.
Board games
No

Board games

Placement on a surface (e.g. desk or shelf) without permanent installation. Ideal for easy use and quick setup.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications
Questions

Questions

Do you have a question about the product?

Those users who have this product can help you

Ask for the product

Description & Specifications

The Aruba AP-503 (RW) access point provides dual-band Wi‑Fi 6 connectivity at 2.4 GHz and 5 GHz, with 2x2 MIMO technology. It is suitable for indoor use and features one RJ‑45 Ethernet port with LAN speeds of up to 1000 Mbps, as well as PoE support.

The built-in omnidirectional antenna offers a gain of up to 1.7 dBi in the 2.4 GHz band and up to 4.8 dBi in the 5 GHz band. WPA, WPA2 and WPA3 are supported. The access point also features a TPM module, a reset button, and LED indicators for reset, status and system.

  • Wi‑Fi generation: Wi‑Fi 6
  • Networking standards: IEEE 802.11a, 802.11b/g/n, 802.11ac, 802.11ax
  • Frequency: Dual-band 2.4 GHz and 5 GHz
  • Maximum WLAN speed: 1467 Mbps
  • MIMO technology: 2x2
  • Antenna type: Built-in omnidirectional
  • Maximum antenna gain: 1.7 dBi at 2.4 GHz and 4.8 dBi at 5 GHz
  • Ethernet ports: 1 RJ‑45
  • LAN speed: 1000 Mbps
  • USB ports: 1 USB Type‑A
  • USB version: USB 2.0
  • PoE support: Yes
  • Security: WPA, WPA2 and WPA3
  • Features: TPM module, reset button and LED indicators
  • Mounting: Indoor
  • Weight: 255 g
  • Dimensions: 145 x 145 x 35 mm
  • Operating temperature: 0–40 °C
  • Storage temperature: −25–55 °C
  • Operating relative humidity: 10–100%
  • Relative humidity range: 5–95%
  • Certification: Low Voltage Directive (LVD)
  • Packaging: Single kit
