EP-SG7810 FOR YOUR HOME NETWORK
As the future of home entertainment becomes increasingly wireless, EDUP's family of home networking devices takes advantage of the latest technology, finally combining both entertainment and convenience.
- Port: 8 ports 10/100/1000M RJ45
- Chipset: RTL8370N
- Number of ports: 8 ports 10/100M/1000M Auto MDI-MDIX RJ45
- Standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3az
- Network media: 10Base-T, cat3 or higher UTP, 10Base-Tx, cat5 UTP
- Data rate: 10/100M/1000M
- Forwarding rate: 10 Mbps / 14,880 pps, 100 Mbps / 148,800 pps, 1000Mbps/1488000pps
- LED indicator: 10/100M/1000Mbps (Link/Act), Power, VLAN Indicator
- Dimensions: 160*72*24mm
- Power input: DC5V/1000mA
- Power consumption: Max 4.5W
- Environment: Operating temperature: 0 ℃-50 ℃, Relative Humidity: 10%-90% (non-condensing)
- Storage temperature: -40℃-70℃, Relative Humidity: 5%-90% (non-condensing)
- Other function: VLAN switch
Network Specifications
- Type
- Unmanaged
- Layer
- L2
- PoE
- No
Technical Specifications
- Ethernet connections
- 8 Port
- Ethernet Speed
- 100 Mbps
- Switching Speed
- -
- Rack mounting
- No
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
