Spamel On-Off switch Rocker Double 1pcs
On-Off switches

Spamel On-Off switch Rocker Double 1pcs Code: ST22-P.CZ-10.

Complete, two-position, rotary lever switch P - ST22-P.CZ-10.

  • Nominal insulation voltage: Ui 500V
  • Rated DC current: Iu=Ith 10A
  • Rated switching current:
    • AC-15: 2.5A (230V), 1.6A (400/500V)
    • DC-13: 4A...

Complete, two-position, rotary lever switch P - ST22-P.CZ-10.

  • Nominal insulation voltage: Ui 500V
  • Rated DC current: Iu=Ith 10A
  • Rated switching current:
    • AC-15: 2.5A (230V), 1.6A (400/500V)
    • DC-13: 4A (24V), 1A (110V), 0.25A (220V)
  • Short-circuit protection: 10 A (quick fuse link), 1 kA (expected short-circuit current for Ue = 500 V)
  • Mechanical endurance: 0.3...
See full description See full description
21 50 €
22 Coins 22 Coins
Delivery Wed, 19 Aug - Tue, 25 Aug
2,50 € to a Skroutz Point
or   3,50 €   shipping cost
Do you want it with Free shipping to Skroutz Point?
From Getters 4.5 (110)
4.5 (110 reviews)
Αχαρνές, Αττικής
16 pieces
See Microelectronic Components on the page of Getters
What if I change my mind?

No problem, as long as it's within 14 days. We'll come pick it up or you can choose the Skroutz Point that suits you, completely free for up to 2 times per year, and we'll refund your money. Get Skroutz Plus to enjoy unlimited free returns.

Review the product
Product report

Description

Description

Complete, two-position, rotary lever switch P - ST22-P.CZ-10.

  • Nominal insulation voltage: Ui 500V
  • Rated DC current: Iu=Ith 10A
  • Rated switching current:
    • AC-15: 2.5A (230V), 1.6A (400/500V)
    • DC-13: 4A (24V), 1A (110V), 0.25A (220V)
  • Short-circuit protection: 10 A (quick fuse link), 1 kA (expected short-circuit current for Ue = 500 V)
  • Mechanical endurance: 0.3 million (switching cycles)
  • Electrical endurance: 0.2 million (at rated voltages and switching currents), 1.0 million (switching cycles)
  • Connection frequency: up to 360 h-1
  • Ambient temperature: -40 ... +70°C (operation), -40 ... +70°C (storage)
  • Vibration resistance: 2...13, 2...100 Hz (frequency), ± 1 mm (amplitude), ± 0.7 g (acceleration)
  • Surge resistance: 15 g (maximum acceleration), 11 ms (pulse duration)
  • Resistance to thermal cycling fluids: 55°C (ambient temperature), 95% (relative humidity)
  • Resistance to cyclic salt mist: testing clarity 1
  • Protection rating: IP65
  • Connection cable cross-section: 2× 1...2.5 mm² (solid wire), 2× 0.75...1.5 mm² (stranded)
  • Working position: any
  • Terminal identification: PN-EN 50013
  • Compliance with the standard: PN-EN 60947-5-1, IEC 60947-5-1, IEC 60947-1

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Product Number
ST22-P.CZ-10.
Type
Rocker
Colour
Black
Features
Double

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications
Questions

Questions

Do you have a question about the product?

Those users who have this product can help you

Ask for the product

Description & Specifications

Complete, two-position, rotary lever switch P - ST22-P.CZ-10.

  • Nominal insulation voltage: Ui 500V
  • Rated DC current: Iu=Ith 10A
  • Rated switching current:
    • AC-15: 2.5A (230V), 1.6A (400/500V)
    • DC-13: 4A (24V), 1A (110V), 0.25A (220V)
  • Short-circuit protection: 10 A (quick fuse link), 1 kA (expected short-circuit current for Ue = 500 V)
  • Mechanical endurance: 0.3 million (switching cycles)
  • Electrical endurance: 0.2 million (at rated voltages and switching currents), 1.0 million (switching cycles)
  • Connection frequency: up to 360 h-1
  • Ambient temperature: -40 ... +70°C (operation), -40 ... +70°C (storage)
  • Vibration resistance: 2...13, 2...100 Hz (frequency), ± 1 mm (amplitude), ± 0.7 g (acceleration)
  • Surge resistance: 15 g (maximum acceleration), 11 ms (pulse duration)
  • Resistance to thermal cycling fluids: 55°C (ambient temperature), 95% (relative humidity)
  • Resistance to cyclic salt mist: testing clarity 1
  • Protection rating: IP65
  • Connection cable cross-section: 2× 1...2.5 mm² (solid wire), 2× 0.75...1.5 mm² (stranded)
  • Working position: any
  • Terminal identification: PN-EN 50013
  • Compliance with the standard: PN-EN 60947-5-1, IEC 60947-5-1, IEC 60947-1

Manufacturer

Manufacturer Details

Warnings & Safety Information
Product Number
ST22-P.CZ-10.
Type
Rocker
Colour
Black
Features
Double

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
