Inverter Description:

• Capacity: 3500 W (5000 VA)
• Battery Voltage: 48 V DC
• Operating Mode: PV (PV priority) / AC (AC priority)

PV Operation:

• Input Voltage Range: 60V DC - 100V DC
• Charging Current: 60 A (depending on the photovoltaic cell)
• Conversion Efficiency: 98%

AC Operation:

• Input Voltage Range: 200V AC ~ 275V AC
• Input Frequency Range: 45-65 Hz
• Output Voltage Range: 206V AC ~ 242V AC
• Efficiency: >= 96%
• Charging Current: 10 A

Inverter Output:

• Inverter Output Voltage: 230 V ± 3%
• Output Frequency: 50 Hz / 60 Hz ± 0.3 Hz
• Output Power Factor: >= 0.8
• Waveform Distortion at Resistance: 80%
• Inverter Overload: 110% -130% shutdown after 30s, 130% -150% shutdown after 3s
• Automatic Shutdown on Short Circuit: Yes
• Battery Capacity: 100-200 Ah (recommended: 200 Ah)
• Estimated Charging Time: 4-14 hours (depending on battery capacity)

Other Information:

• Ambient Temperature: 0 ~ 40 °C
• Humidity: 10% ~ 90%
