Spamel On-Off switch 1pcs
On-Off switches

Spamel On-Off switch 1pcs Code: SK40-4.8396P03

On-Off Switch

  • Ue: 690 V
  • Uimp: 6 kV
  • Iu=Ith: 50 A
  • Ie AC-21A, AC-22A: 40 A (230/400/500/690 V)
  • Pe AC-23A: 9 kW (230 V), 15 kW (400 V), 18.5 kW (500 V), 26 kW (690 V)
  • Pe AC-3: 7.5 kW (230 V), 12 kW (400...

On-Off Switch

  • Ue: 690 V
  • Uimp: 6 kV
  • Iu=Ith: 50 A
  • Ie AC-21A, AC-22A: 40 A (230/400/500/690 V)
  • Pe AC-23A: 9 kW (230 V), 15 kW (400 V), 18.5 kW (500 V), 26 kW (690 V)
  • Pe AC-3: 7.5 kW (230 V), 12 kW (400 V), 15 kW (500 V), 21 kW (690 V)
  • Ie DC-21A: 40 A (24 V), 20 A (110 V), 15 A (220 V)
  • Icw(1s): 0.5 kA
  • Icm: 0.7 kA
  • Conventional short-circuit current: 10 kA
  • gG...
See full description See full description
68 05 €
69 Coins 69 Coins
Delivery Mon, 12 Oct - Fri, 16 Oct
2,50 € to a Skroutz Point
Do you want it with Free shipping?
Sent from Poland
From Ovolt 4.7 (11)
4.7 (11 reviews)
Poland
20+ pieces
See Microelectronic Components on the page of Ovolt
What if I change my mind?

No problem, as long as it's within 14 days. We'll come pick it up or you can choose the Skroutz Point that suits you, completely free for up to 2 times per year, and we'll refund your money. Get Skroutz Plus to enjoy unlimited free returns.

Review the product
Product report

Description

Description

On-Off Switch

  • Ue: 690 V
  • Uimp: 6 kV
  • Iu=Ith: 50 A
  • Ie AC-21A, AC-22A: 40 A (230/400/500/690 V)
  • Pe AC-23A: 9 kW (230 V), 15 kW (400 V), 18.5 kW (500 V), 26 kW (690 V)
  • Pe AC-3: 7.5 kW (230 V), 12 kW (400 V), 15 kW (500 V), 21 kW (690 V)
  • Ie DC-21A: 40 A (24 V), 20 A (110 V), 15 A (220 V)
  • Icw(1s): 0.5 kA
  • Icm: 0.7 kA
  • Conventional short-circuit current: 10 kA
  • gG fuse: 50 A
  • Conductor cross-section: 4...10 mm²
  • Terminal torque: 1.2 Nm
  • Mounting: □48
  • Mechanical durability: 3.0 million switching cycles
  • Temperature: -40 ... +70°C (operation and storage)
  • Protection: IP65
  • Vibration: IEC 60068-2-6, 2...13, 2...100 Hz, ± 1 mm, ± 0.7 g
  • Shocks: IEC 60068-2-27, 15 g, 11 ms
  • Periodic damp heat: IEC 60068-2-30, 55°C, 95%
  • Salt spray: IEC 60068-2-52, Test severity 1
