Spamel On-Off switch with Lighting 1pcs
On-Off switches

Spamel On-Off switch with Lighting 1pcs Code: SK16-2.8211OB11

The Spamel SK16-2.8211OB11 is an illuminated On-Off switch. It has a rated insulation voltage of 690 V, a rated impulse withstand voltage of 6 kV, and a rated current of 20 A.

  • Illumination:...

The Spamel SK16-2.8211OB11 is an illuminated On-Off switch. It has a rated insulation voltage of 690 V, a rated impulse withstand voltage of 6 kV, and a rated current of 20 A.

  • Illumination: Illuminated
  • Rated insulation voltage (Ue): 690 V
  • Rated impulse withstand voltage (Uimp): 6 kV
  • Continuous rated current (Iu=Ith): 20 A
  • Rated current Ie AC-21A, AC-22A: 16...
See full description See full description
38 90 €
Delivery Mon, 23 Nov - Fri, 27 Nov
2,50 € to a Skroutz Point
Do you want it with Free shipping?
From Getters 4.5 (117)
4.5 (117 reviews)
Αχαρνές, Αττικής
See Microelectronic Components on the page of Getters

Shop selection criteria

Why do we recommend buying from this shop?

We don’t only look at the price. We weigh different factors to find an offer that combines a good price, fast delivery and a reliable purchase.

  • Product price

    We calculate the total price you will pay and any discounts available from the shop.

  • Shipping & delivery time

    We check how quickly the product can be shipped and when you will receive it, based on your address.

  • Shop reliability

    We look at how often shops complete their orders successfully and how consistently they serve their customers.

  • Official reseller

    Where available, we take into account whether the shop is an official reseller of the brand.
What if I change my mind?

No problem, as long as it's within 14 days. We'll come pick it up or you can choose the Skroutz Point that suits you, completely free for up to 2 times per year, and we'll refund your money. Get Skroutz Plus to enjoy unlimited free returns.

Review the product
Product report

Description

Description

The Spamel SK16-2.8211OB11 is an illuminated On-Off switch. It has a rated insulation voltage of 690 V, a rated impulse withstand voltage of 6 kV, and a rated current of 20 A.

  • Illumination: Illuminated
  • Rated insulation voltage (Ue): 690 V
  • Rated impulse withstand voltage (Uimp): 6 kV
  • Continuous rated current (Iu=Ith): 20 A
  • Rated current Ie AC-21A, AC-22A: 16 A (230/400/500/690 V)
  • Power Pe AC-23A: 3 kW (230 V), 5 kW (400 V), 6 kW (500 V), 8 kW (690 V)
  • Power Pe AC-3: 2 kW (230 V), 3.5 kW (400 V), 4 kW (500 V), 6 kW (690 V)
  • Rated current Ie DC-21A: 16 A (24 V), 8 A (110 V), 6 A (220 V)
  • Short-time withstand current (Icw, 1 s): 0.25 kA
  • Peak current (Icm): 0.34 kA
  • Short-circuit current: 10 kA
  • gG fuse: 16 A
  • Conductor cross-section: 1–4 mm²
  • Terminal torque: 0.5 Nm
  • Mounting: 31/□36
  • Mechanical endurance: 3.0 million switching cycles
  • Operating temperature: -40 to +70 °C
  • Storage temperature: -40 to +70 °C
  • Degree of protection: IP65
  • Vibration (IEC 60068-2-6): 2–13 and 2–100 Hz, ±1 mm, ±0.7 g
  • Shock (IEC 60068-2-27): 15 g, 11 ms
  • Cyclic damp heat (IEC 60068-2-30): 55 °C, 95% relative humidity
  • Cyclic salt mist (IEC 60068-2-52): Test severity 1

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Product Number
SK16-2.8211OB11
Colour
-
Features
with Lighting

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications
Questions

Questions

Do you have a question about the product?

Those users who have this product can help you

Ask for the product

Description & Specifications

The Spamel SK16-2.8211OB11 is an illuminated On-Off switch. It has a rated insulation voltage of 690 V, a rated impulse withstand voltage of 6 kV, and a rated current of 20 A.

  • Illumination: Illuminated
  • Rated insulation voltage (Ue): 690 V
  • Rated impulse withstand voltage (Uimp): 6 kV
  • Continuous rated current (Iu=Ith): 20 A
  • Rated current Ie AC-21A, AC-22A: 16 A (230/400/500/690 V)
  • Power Pe AC-23A: 3 kW (230 V), 5 kW (400 V), 6 kW (500 V), 8 kW (690 V)
  • Power Pe AC-3: 2 kW (230 V), 3.5 kW (400 V), 4 kW (500 V), 6 kW (690 V)
  • Rated current Ie DC-21A: 16 A (24 V), 8 A (110 V), 6 A (220 V)
  • Short-time withstand current (Icw, 1 s): 0.25 kA
  • Peak current (Icm): 0.34 kA
  • Short-circuit current: 10 kA
  • gG fuse: 16 A
  • Conductor cross-section: 1–4 mm²
  • Terminal torque: 0.5 Nm
  • Mounting: 31/□36
  • Mechanical endurance: 3.0 million switching cycles
  • Operating temperature: -40 to +70 °C
  • Storage temperature: -40 to +70 °C
  • Degree of protection: IP65
  • Vibration (IEC 60068-2-6): 2–13 and 2–100 Hz, ±1 mm, ±0.7 g
  • Shock (IEC 60068-2-27): 15 g, 11 ms
  • Cyclic damp heat (IEC 60068-2-30): 55 °C, 95% relative humidity
  • Cyclic salt mist (IEC 60068-2-52): Test severity 1
