Smart Home AX 40 10Nm TrendLine roller mechanism with built-in radio receiver.
Description: The AX 40 motor, 10Nm, features a built-in radio receiver. The diameter of the motor body is 35mm. The motor head ensures quick and easy installation and can also be used in industrial production. The tubular motor requires zero maintenance, has a long lifespan, and features thermal protection against overload. The simple mechanical adjustment of the end positions and the silent operation mechanism make this series particularly successful.
- Motor with mechanical adjustment.
- Sold with a mounting plate.
- The upper/lower limiters are very easy to adjust with the mechanisms at the motor head.
- Long-term retention of end positions during power outages.
- Simple and fast installation.
- Requires zero maintenance, has a long lifespan, thermal protection against overload, and silent operation.
Specifications: The motor is TV certified. Dimensions, length without bearings: 540mm. Motor diameter: 35mm. Revolutions per minute: 17rpm. Capacity: 146W. Nominal torque: 10Nm. Maximum load: 26kg. Cable length: 1.5m. Shaft diameter: 40mm octagonal.
- Torque
- 10 Nm
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
