Speaker Size: 4.3 inches
Impedance: Z 4Ω
DC Resistance: Re 3.6Ω
Voice Coil Diameter: Ø 25.5 mm
Voice Coil Inductance: Le 0.09 mH
Voice Coil Support Material: Kapton CCAW
Diaphragm Material: Carbon fiber reinforced with resin
Magnet System: Ms Neodymium
Net Weight: 0.36 kg
Transducer Suspension Qms: Qms 6.08
Transducer Suspension Qts: Qts 0.65
Motor Force: Bl 3.76
Centering Mechanism: Cd Konex
Suspension Cone: Sc Rubber 50sh
Resonance Frequency: Fs 97 Hz
Frequency Response: Fr 100 Hz - 12 kHz
Performance 1 W / 1 m: SPL 86 dB
Rated Capacity / High-Pass Filter at 1500 Hz: RMS 70W
Dimensions
- Type
- Midrange
- Shape
- Round
Technical Specifications
- Power (RMS)
- 70 W
- Nominal Impendance
- 4 ohm
