The DD Audio Class A mono car amplifier delivers 2,200 W of continuous power at 2 Ω and 3,000 W at 1 Ω. Its frequency response spans 20 Hz to 20,000 Hz, and it features a subsonic filter and a low-pass filter.
- Input channels: 2
- Output channels: 1
- Amplifier class: A
- Operating voltage: 9–16 V
- Test voltage: 14.4 V
- Continuous power at 2 Ω: 2,200 W
- Continuous power at 1 Ω: 3,000 W
- Maximum current: 300 A
- RCA input sensitivity: 0.25–6 V
- RCA signal-to-noise ratio: 95 dB
- Damping factor: 100
- THD: 1.0%
- Frequency response: 20–20,000 Hz
- Subsonic filter: 20–80 Hz
- Low-pass filter: 80–20,000 Hz
- Remote control: Included
- Power cable gauge: 0 AWG
- Speaker cable gauge: 4 AWG
- Dimensions: 221 × 185 × 60 mm
- Weight: 2.27 kg
- Number of Channels
- 1 Channel
- Output Power (4 Ohm)
- -
- Amplifier class
- A
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
