Product Data:
- Model: TRF SPL SW1865CC D0.5 or D0.7 or D1 Ohm
- Size: 18 inches
- Cone: Carbon
- Surround Material: Form
- Voice Coil: Made in the USA
- Voice Coil Diameter: 4.0 inches
- Voice Coil Layers: 8 layers
- Dust Cap: Carbon
- Nominal Resistance: D0.5 or D0.7 or D1
- Voice Coil Wire: Aluminum
- Spider Diameter: 4'' ID / 10'' OD
- Spider Material: NOMEX
- Spider Layers: 5 pieces x 2 layers
- RMS Capability: 6500wrms
- RMS Program: 20,000 - 25,000wrms (3 seconds)
- Maximum Watt: 13000wmax
- Sensitivity: dB
- Resonant Frequency (f0): - Hz
- Mechanical Q Factor (Qms): -
- Electrical Q Factor (Qes): -
- Total Q Factor (Qts): -
- Xmax: mm
- Power Factor: N/A
- Magnet Weight: - Oz
- Net Weight: 45kg
- Basket: Cast aluminum
- Magnet: Ferrite
- Magnet Size: Φ280*25mm x 3PCS
- External Dimension: 450mm
- Installation Depth: 341mm
- Magnet Dimension: 280mm
- Installation Hole Size: 425mm
- Power (RMS)
- 6500 W
- Functionality
- Passive
- with Box
- No
- Diameter
- 18 "
