Features:
- Amplifier with Mixer 2x50W/4Ω, 2x25W/8Ω, Class-D.
- High-quality Class-D amplifier that provides optimized performance and excellent sound quality through digital internal processing.
- Opti-voice paging for smooth and automatic transition between music and announcement signals.
- On the front panel: MIC/LINE INPUT with balanced XLR-TRS, MIC/LINE INPUT GAIN (0 dB to +50 dB), AUX INPUT – 3.5 mm (1/8”) stereo line-level input connector.
- INPUT A/B selector switch, TREBLE/BASS controls, MASTER LEVEL.
- On the rear panel: INPUT A/B with stereo RCA INPUT GAIN for signal level adjustment -20 dB to +20 dB on inputs A/B.
- PAGE INPUT, Euroblock mic/line input with contact closure for use with push-to-talk microphone.
- PAGE INPUT GAIN, for signal level adjustment 0 dB to +50 dB on the page input.
- REMOTE, input jack for CC-1 volume control (works with input B) or CC-2 volume control with A/B source selection.
- AUX OUT, line output with level adjustment capability.
- EQ, presets for FreeSpace FS2 and FS4 loudspeakers.
- Rack mount 1U, half rack.
- Dimensions 45 x 214 x 310 mm.
- Weight, 2.2 kg.
Technical Specifications
- Amplifier Type
- Commercial Amplifier
- Type
- Preamplifier
- Channels
- 2
- Power (8Ω)
- 25 watt / channel
- Power (4Ω)
- 50 watt / channel
- Class
- D
Additional Specifications
- Radio
- No
- Cooling system
- No
Connectivity
- RCA
- Yes
- XLR
- No
- Mini Jack (3.5mm)
- No
- Jack (6.3mm)
- No
- USB
- No
- Ethernet
- No
- Bluetooth
- No
- Mic In
- Yes
Dimensions
- Width
- 214 mm
- Height
- 45 mm
- Length
- 310 mm
