The Limetree PHONO II is Lindemann's statement for all vinyl lovers. A high-quality preamplifier for your cartridge. Using the latest technologies and parts, we have revitalized a circuit design from the tube era. The result is absolutely unparalleled! Rediscover the exceptional sound experience!

Features

• Two discrete inputs, perfectly tailored for the respective type of cartridge, ensuring the best sound quality with MM and MC cartridges.
• Easy installation, just plug it in and you're ready to go.
• For MC, there is an adjustable input compensation between 50 and 400 ohms.
• The measured parameters of the PHONO are excellent, with noise and distortions close to the limits of resolution.
• The sound quality and amplifier technology play in a league of their own.

Technology

• The Limetree PHONO II is based on a circuit design from the classic tube era, with a completely new interpretation using the latest technologies and components.
• The two-stage circuit layout with passive RIAA equalization network uses the best J-FET amplifiers and ultra-precise resistors and capacitors from Japan.
• The purely passive equalization has a significant advantage: distortions in the bass range are much lower.
• For power supply, we use a "medical-grade" external power transformer, ensuring particularly good isolation from line disturbances.
• Together with advanced onboard filtering and special voltage regulators, we have managed to implement an extremely low-noise power supply, with contaminating voltage below 10 µV.

Technical Specifications

• Testing conditions: 22 °C, 230 V mains voltage, Audio Precision AP2722
• Power consumption: 0.1 W in standby, 0.8 W MM, 0.6 W MC
• Dimensions (W x H x D): 107 x 40 x 130 mm
• Weight: 295 g
• MM Gain: 40 dB
• MC Gain: 66 dB
• Equalization: RIAA characteristic, overall deviation + 0 dB, - 0.5 dB
• THD: 82 dBV (A-weighted, 600 ohms termination, referred to 1 V output voltage)
• S/N MC: > 72 dBV (A-weighted, 10 ohms termination, referred to 1 V output voltage)
