MAXIMUM ENERGY USE
Made from high-quality steel resistant to very high temperatures. Efficient combustion process and temperature maintenance for prolonged heating thanks to the combustion lining with TERMOTEC - a heat accumulation material that increases the temperature in the combustion masonry. High smoke chamber and transverse smoke pipe - increases the heat exchange surface between the device and the environment. Reducing the temperature of gas emissions helps increase the efficiency of the device.
Fireplace door mechanisms resistant to stress and stable thanks to the use of a closed profile. Door seals designed in a channel profile, guaranteeing proper adhesion and protection from potential falling during operation. Combustion of fuel particles thanks to the exclusive diffuser, which extends the path of exhaust gases.
Air supplied only from the outside thanks to the built-in external air inlet fi 125mm. Air adjustment with a single regulator, preventing incorrect use. Triple air system in the combustion masonry: primary air - directed to the combustion plate, secondary air supplied through holes located in the rear wall. Additionally, a clean air system for the glass (air curtain) has been applied.
PERFECT LEVEL OF SAFETY
Perfect tightness thanks to solid welds made in protective gas. All steel elements are laser cut and bent on CNC machines. The front part of the device is equipped with heat-resistant ceramics that withstand temperatures up to 660oC.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which specifies the maximum CO emission.
COMFORT OF USE
Grate-free fireplace insert - complete combustion of dust, meaning that wood burns into fine ash in minimal amounts. The thermal energy derived from the wood is utilized to the maximum. The lower plate of the device is significantly reduced in relation to the door. Reduced smoke deposition through the clean glass system (air curtain). The specially designed peripheral handle design is protected from overheating, which affects the high comfort of using the fireplace.
MODERN DESIGN
Fireplace insert with two glass surfaces assembled together at angles (without supports). Decorative, heat-resistant glass that can withstand temperatures up to 660oC. Gives the fireplace a modern and elegant appearance, visually expanding the front part of the device. The doors are equipped with a modern handle.
- Product Number
- MBZ/PF/BLACK
Product Details
- Cassette
- No
- Air Ηeater
- Yes
- Air Duct Connection
- No
- Radiator
- No
- Chimney diameter
- 200 mm
- Material
- Steel
- Fuel
- Wood
- Weight
- 185 kg
Performance
- Energy Class
- A
- Total Power
- 13 kW
- Power in the Air
- 13 kW
- Performance Level
- 81 %
- Water Consumption
- 5.34 kg/h
Attributes
- Windows
- Straight
- Container
- -
- Doors
- with an opening door
Dimensions
- Height
- 1400 mm
- Width
- 730 mm
- Length
- 475 mm
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
