Keysight MSOX3054G Oscilloscope & Frequency Generator Counter 500MHz With 4 Analog Channels And 8.5" Monitor
Oscilloscopes & Frequency Generators

Keysight MSOX3054G Oscilloscope & Frequency Generator Counter 500MHz With 4 Analog Channels And 8.5" Monitor

The new Keysight MSOX3054G500 MHz, 4-channel digital oscilloscope offers cutting-edge technology from Keysight combined with 8 new standard capabilities and features.

The new Keysight MSOX3054G500 MHz, 4-channel digital oscilloscope offers cutting-edge technology from Keysight combined with 8 new standard capabilities and features.

See full description See full description
22607 68 €
22,61€ cashback in Coins 22,61€ cashback in Coins
Delivery Tue, 04 Aug - Mon, 10 Aug
Free   shipping cost
From NsMarket
Νέα Φιλαδέλφεια, Αττικής
See Multimeters on the page of NsMarket
What if it breaks?

You're covered by the statutory 2-year warranty. Contact us and we'll handle the entire process with the store, ensuring your issue is resolved with prompt support through a repair, replacement, or refund.

What if I change my mind?

No problem, as long as it's within 14 days. We'll come pick it up or you can choose the Skroutz Point that suits you, completely free for up to 2 times per year, and we'll refund your money. Get Skroutz Plus to enjoy unlimited free returns.

Review the product
Product report

Description

Description

The new Keysight MSOX3054G500 MHz, 4-channel digital oscilloscope offers cutting-edge technology from Keysight combined with 8 new standard capabilities and features.

With the integrated MegaZoom IV circuit, the oscilloscope performs hardware-based serial decoding, displays analog and digital signals directly on the screen, and fully utilizes memory (segmented memory mode) for maximum sampling rate (5 GSa/s). This achieves a very high waveform update rate (>1,000,000 wfms/sec) for optimal signal representation and fault detection. Additionally, with the revolutionary zone touch triggering feature, isolate the signal of interest in seconds by simply drawing a frame on the screen.

Key Features:

  • 4 analog channels
  • 16 digital channels
  • Largest touch screen in its category: 8.5" WVGA
  • Waveform update rate: 1,000,000 waveforms/sec
  • Maximum sampling rate: 5 GSa/s
  • Maximum memory depth: up to 4 Mpts (with half channels in operation)
  • Built-in 20 MHz frequency generator (standard)
  • Histogram mode (standard)
  • Serial decoding and triggering (standard): I2C, SPI, UART, I2S, USB PD
  • Mask Limit Testing (standard)
  • Measurement Limit Testing (standard)
  • Frequency response analysis with Bode plots (standard)
  • Enhanced HDTV video analysis (standard)
  • LAN/VGA connectivity (standard)
  • Built-in logic analyzer (with optional upgrade)
  • 3-digit voltmeter
  • Connectivity with computer and remote use via Pathwave Benchvue
  • Upgradeability: add bandwidth, digital channels

Included in the package:

4 passive probes 10:1 (1 for each channel), calibration certificate, CD with user manuals, one MSO N2756A 16-channel digital cable, power cable

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Dimensions

Type
Counter
Monitor Size
8.5 "
Bandwidth
500 MHz
Channels
4
Weight
4.2 kg
Height
20.4 cm
Length
38.1 cm
Width
14.2 cm

Signal Modulation

AM
No

AM

Information is transmitted by varying the amplitude (intensity) of the carrier signal while the frequency remains constant. It is used in RF applications and communications testing.
FM
No

FM

The information is transmitted through changes in the frequency of the carrier signal. It offers greater noise resistance compared to AM.
PM
No

PM

The information is transmitted through changes in the phase of the carrier signal. It is used in telecommunications and digital transmission systems.
PWM
No

PWM

Information is encoded by changing the duration (duty cycle) of the pulses while the amplitude remains constant. Common in power electronics and motor control.
FSK
No

FSK

Digital modulation where different frequencies correspond to different digital values (e.g., 0 and 1). It is used in modems and wireless communications.
ASK
No

ASK

Digital modulation where the information is represented by changes in the signal amplitude. It is used in simple data transmission systems.
PSK
No

Waveform Types

Sin
No

Sin

(Sinusoidal) Produces a smooth periodic waveform with continuous amplitude variation. Used in tests of electronic circuits, audio, and telecommunications.
Square
No

Square

Generates a signal that alternates between two voltage levels with abrupt transitions. Suitable for digital circuits and timing tests.
Ramp
No

Ramp

Produces a signal with a linear increase or decrease in voltage over time before the cycle repeats. Used in scanning, timing, and control systems.
Pulse
No

Pulse

Generates short pulses with adjustable amplitude and duration. Useful for testing digital circuits and analyzing system response.
Arbitrary
No

Arbitrary

Allows the creation or loading of custom waveforms beyond the predefined signal shapes. Suitable for specialized measurements and simulations.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
