Outer diameter of the shaft: Ø8mm
Maximum response frequency: 300kHz
Maximum allowable revolutions per minute: 5000rpm
Starting torque: Max. 70gf.cm (max. 0.00686N.m)
Resolution: 500P/R
Control output: Totem pole
Power supply: 12-24VDC ±5% (ripple P-P: max. 5%)
Connection type: Cable type shaft
Protection structure: IP50 (IEC standard)
- Type
- Rotary Enconter
