Technical specifications:

• Inputs SAT polarities + Terrestrial: 8+1
• Taps: 8
• Trunk loss SAT 950...2150 MHz (dB): -1...-2
• Trunk loss Terrestrial 5...862 MHz (dB): -3...-4
• Tap loss SAT 950...2150 MHz (dB): 0...+4
• Active Terrestrial 47...862 MHz (dB): -4...0
• Passive Terrestrial 5...862 MHz (dB): -24...-20
• Return loss SAT 950...2150 MHz (dB): >10
• Return loss Terrestrial 5...862 MHz (dB): >10
• Isolation SAT to Terrestrial (dB): >60
• Isolation Terrestrial to SAT (dB): >24
• Cross polarization H/V (dB): >30
• Output level SAT (IMD3, EN50083-5) (dBμV): 100
• Output level Terrestrial (IMD3, EN50083-5) (dBμV): 92
• LNB power supply: 13 VDC/1500 mA
• Consumption from the receiver (mA): 40
• Switching commands: DisEqC2.0 - 13V/18V, 0/22 KHz, Tone
• Dimensions (LxWxH) (mm): 110x190x40
• Universal, standalone/cascadable
