Ledvance Dimmable LED Power Supply IP20 Power 150W with Output Voltage 24V
LED Power Supplies

Ledvance Dimmable LED Power Supply IP20 Power 150W with Output Voltage 24V

Technical Data

  • Rated power consumption: 150.00 W
  • Output power: 150 W
  • Rated voltage: 220…240 V
  • Output voltage: 24 V
  • Voltage range: 220…240 V
  • Input voltage: 198…264 V
  • U-OUT: 24 V
  • Type of current: DC
  • ...

Technical Data

  • Rated power consumption: 150.00 W
  • Output power: 150 W
  • Rated voltage: 220…240 V
  • Output voltage: 24 V
  • Voltage range: 220…240 V
  • Input voltage: 198…264 V
  • U-OUT: 24 V
  • Type of current: DC
  • Rated current: 950 mA
  • Output current: 6250 mA
  • Inrush current: 55 A
  • Output ripple current (100 Hz): 0.90
  • Efficiency ECG: 87 %
  • Device power losses: 14.8 W
  • Maximum...
See Description & Specifications See Description & Specifications
37 18 €
38 Coins 38 Coins
Delivery by Wed, 21 Oct
2,50 € to a Skroutz Point
Do you want it with Free shipping?
From Electremporiki 4.6 (27)
4.6 (27 reviews)
Θεσσαλονίκη, Θεσσαλονίκης
In-store pickup available
2 pieces
See LED Strips & Accessories on the page of Electremporiki
What if it breaks?

You're covered by the statutory 2-year warranty. Contact us and we'll handle the entire process with the store, ensuring your issue is resolved with prompt support through a repair, replacement, or refund.

What if I change my mind?

No problem, as long as it's within 14 days. We'll come pick it up or you can choose the Skroutz Point that suits you, completely free for up to 2 times per year, and we'll refund your money. Get Skroutz Plus to enjoy unlimited free returns.

Questions
Review the product
Product report

Description & Specifications

Technical Data

  • Rated power consumption: 150.00 W
  • Output power: 150 W
  • Rated voltage: 220…240 V
  • Output voltage: 24 V
  • Voltage range: 220…240 V
  • Input voltage: 198…264 V
  • U-OUT: 24 V
  • Type of current: DC
  • Rated current: 950 mA
  • Output current: 6250 mA
  • Inrush current: 55 A
  • Output ripple current (100 Hz): 0.90
  • Efficiency ECG: 87 %
  • Device power losses: 14.8 W
  • Maximum number of ECG on 10 A fuse (B): 3
  • Maximum number of ECG on 16 A fuse (B): 5
  • Maximum number of ECG on 25 A fuse (B): 6
  • Surge withstand voltage (L/N): 1 kV
  • Galvanic isolation: SELV
  • ECG lifetime: 35000 h

Dimensions & Weight

  • Length: 268.00 mm
  • Mounting hole distance, length: 251 mm
  • Width: 45.00 mm
  • Height: 30.50 mm
  • Product weight: 408.00 g

Colors & Materials

  • Product color: white
  • Housing material: Plastic
  • Frame material: Plastic

Temperature & Operating Conditions

  • Ambient temperature range: -20…45 °C
  • Max. temperature at test point: tc 85 °C
  • Operating temperature range: -20…+45 °C
  • Relative humidity: 20…90 %

Features

  • Dimmable: No
  • Overtemperature protection: Yes
  • Overload protection: Yes
  • Short-circuit protection: Yes
  • Type of connection, output side: Screw terminal

Certificates & Standards

  • Approval marking: CE
  • Standards: According to EN 61347-1, EN 61347-2-13, EN 55015, EN 61547, EN 61000-3-2, EN 62384
  • Insulation class: II
  • Protection degree: IP20

Manufacturer

Manufacturer Details

Warnings & Safety Information
Type
Plastic
Output (DC)
24 V
Power
150 W
Waterproofing
IP20
Features
Dimmable

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
