Specifications:
- Number of inputs (Satellite + Terrestrial): 16+1
- Satellite frequency range: 950 - 2150 MHz
- Terrestrial frequency range: 47 - 870 MHz
- Connector: F-female
- Impedance: 75Ω
- Switching commands: 13/18 V, 0/22 kHz, DiSEqC 2.0, Toneburst VDC
- Number of subscribers: 8
- Satellite gain: +3dB ±2
- Terrestrial gain: +3dB ±1
- Max output level @ -35dB (IMD3): 102dBμV
- Isolation:
- Satellite subscriber-subscriber: >34dB
- Satellite-Satellite: >34dB
- Satellite-Terrestrial: >36dB
- Cross-polarization H/V: >34dB
- Number of outputs (Satellite + Terrestrial): 16+1
- Terrestrial Cascade Loss: -5dB ±1
- Satellite Cascade Loss: -2dB ±2
- Power supply: +18VDC (Not included)
- Consumption: 850mA max.
- Operating temperature: 0°C to 40°C
- Storage temperature: -10°C to +70°C
- Humidity: Up to 90%
- Dimensions: 135 x 326 x 35 mm
- Weight: 0.984 Kg
- Type
- Multiswitch
