Description
Specifications
Key System Features
- Energy performance provided: Uf: 1.8 – 2.2 W/m2K, Uw: 1.5 W/m2K with double glazing (Ug: 1.0), Uw: 1.2 W/m2K with triple glazing (Ug: 0.6)
- Three levels of thermal insulation with an additional insulating foam core zone of technology I2
SAFETY
- Certified security WK2 with up to 21 perimeter locking points
ELVIAL WATERPROOFING SYSTEM
- Elastic corners made of EPDM for the central and perimeter seals
- Optimized additional seal for effective waterproofing
- Rated in the highest waterproofing category: E900
DURABILITY FOR A LIFETIME
- Up to 130 kg / leaf up to 2,350mm height
- Excellent functionality with specially designed corners made of polyamide
Technical Specifications
- Frame type: Single-leaf opening thermal insulator
- Manufacturer: Elvial
- Series: 4600 ai2
- Opening direction: Available left and right
- Glazing: Double energy glass 4/15.5/4
- Electrostatic coating: ral 9016 (white)
- Thermal break: Yes
- Sound insulation: Yes
- Anti-burglary protection: Yes
- Sash lock: Yes
- Perimeter frame: Yes
- Sandblasting: Yes
- Recall: Yes
- Certification: Elvial
- Product Number
- EL4600-60-80
- Type
- Window
- Frame & Shutter Type
- Hinged
- Material
- Aluminum
- Roof
- No
- Sound Insulation
- No
- Width
- 60 cm
- Height
- 80 cm
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
