Franklin Electric Submersible Pump Motor (without Motor) 115150013
Submersible Water Pumps

Franklin Electric Submersible Pump Motor (without Motor) 115150013

Submersible oil-lubricated submersible electric motor, suitable for 4" wells with a maximum depth of 250m, with NEMA standard flange.

Operates in conjunction with a deep well pump (body) with the same...

Submersible oil-lubricated submersible electric motor, suitable for 4" wells with a maximum depth of 250m, with NEMA standard flange.

Operates in conjunction with a deep well pump (body) with the same coupling dimensions. Primarily used in vertical installations.

TECHNICAL SPECIFICATIONS

  • Nominal voltage: THREE-PHASE 380-415V/50Hz, 460V/60Hz
  • Power range:...
See full description See full description

  • Horsepower

    Horsepower indicates the kinetic power of the pump. Higher horsepower means more efficiency in water pumping, affecting the flow (l/h) and the head (m).

  • Power

    It is the energy consumed by the motor to pump water. The greater the power, the more effectively it can lift and move water, especially over long distances or heights.
  • See all
This product is temporarily unavailable at Skroutz Last updated: 1 day ago
Review the product
Product report

Description

Description

Submersible oil-lubricated submersible electric motor, suitable for 4" wells with a maximum depth of 250m, with NEMA standard flange.

Operates in conjunction with a deep well pump (body) with the same coupling dimensions. Primarily used in vertical installations.

TECHNICAL SPECIFICATIONS

  • Nominal voltage: THREE-PHASE 380-415V/50Hz, 460V/60Hz
  • Power range: 0.37 kW to 7.5 kW
  • Voltage tolerance: ± 10%
  • Cable length: 0.37-2.2kW=1.5m / 3.0-4.0kW=2.5m / 7.5kW=3.5m
  • Cable dimensions: 4x1.5 mm2
  • Ambient temperature: 30 °C
  • Insulation class: F
  • Protection rating: IP68
  • Number of starts/hour: 30
  • Single-phase motors do not include a capacitor

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Dimensions

Type
Engine
Power Source
Electric

Power Source

Electric
The power supply refers to the pump's need for electrical energy from an external power source, such as single-phase or three-phase power.
Horsepower
3 hp

Horsepower

Horsepower indicates the kinetic power of the pump. Higher horsepower means more efficiency in water pumping, affecting the flow (l/h) and the head (m).
Power
2250 W

Power

It is the energy consumed by the motor to pump water. The greater the power, the more effectively it can lift and move water, especially over long distances or heights.

Features

Electronic Level Sensor
No

Electronic Level Sensor

It automatically activates the pump without the classic hanging float switch. It is ideal for narrow spaces and pits, as there is no risk of it getting stuck anywhere and flooding the area.
with Cutter Impeller
No

with Cutter Impeller

Components that chop, "cut" solid materials, such as organic waste or other particles, before they pass into the pump. They are mainly used in sewage or dirty water pumps, preventing clogging or damage to the system.
Float switch
No

Float switch

It is a mechanism that automatically controls the operation of the pump. When the water level reaches a predetermined height, the float activates the pump.
Outlet Nozzle
4"

Outlet Nozzle

The outlet nozzle refers to the point or the external diameter of the pump from which the pumped water or liquid exits. It is an important feature for determining the connection of the pump with the piping system and affects the flow capacity of the liquid.
Vortex
No

Vortex

The vortex system in submersible water pumps uses vortex technology to create a rotating water current, which helps in the efficient transfer of water, even when it contains particles or solids.

Pumping Specifications

Shallow Suction
No

Shallow Suction

This function allows the pump to suck water from an extremely low level (up to 1-3 mm), ideal for flooded floors and basements.

Materials & Construction

Set
No
Stainless
No
Protection Certification
IP68

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
