Characteristics:

• Dimensions: 600 x 900 x 100 mm (Length x Height x Thickness)
• Weight: 17 kg
• Performance: 820 kcal
• "L" type brackets that provide placement flexibility
• Paint color RAL 9016
• Eco-friendly multi-stage painting process for increased product lifespan
• Test pressure: 13 bar
• Maximum operating pressure: 10 bar
• Steel according to EN 10130
• Sheet metal thickness: 1.2 mm +/- 0.09 mm (EN 442)
• Surface treatment and painting according to DIN 55900-1

The performance of the bodies applies to water temperatures of 90°C inlet, 70°C outlet, and room temperature of 20°C.
