Schneider Electric Automatic Circuit Breaker 4A Single-pole AC/DC A9F07604
Automatic Circuit Breaker

Schneider Electric Automatic Circuit Breaker 4A Single-pole AC/DC A9F07604

Circuit breaker 1P+N C 4A 10kA AC iC60H-C4-1N

  • Device application: Distribution
  • Product name: Acti 9 iC60
  • Product type: Circuit breaker
  • Poles: 1P + N
  • Number of protected poles: 1
  • Rated current: 4 A
  • ...

Circuit breaker 1P+N C 4A 10kA AC iC60H-C4-1N

  • Device application: Distribution
  • Product name: Acti 9 iC60
  • Product type: Circuit breaker
  • Poles: 1P + N
  • Number of protected poles: 1
  • Rated current: 4 A
  • Network type: Alternating current (AC)
  • Trip technology: Thermal-magnetic
  • Characteristic: C
  • Breaking capacity: 70 kA according to EN/IEC 60947-2
  • Usage category:...
See full description See full description
40 45 €
41 Coins 41 Coins
Delivery Wed, 12 Aug - Fri, 14 Aug
2,50 € to a Skroutz Point
Do you want it with Free shipping?
Sent from Poland
From Ovolt 4.5 (14)
4.5 (14 reviews)
Poland
14 pieces
See Electrical Panel Supplies on the page of Ovolt
What if it breaks?

You're covered by the statutory 2-year warranty. Contact us and we'll handle the entire process with the store, ensuring your issue is resolved with prompt support through a repair, replacement, or refund.

What if I change my mind?

No problem, as long as it's within 14 days. We'll come pick it up or you can choose the Skroutz Point that suits you, completely free for up to 2 times per year, and we'll refund your money. Get Skroutz Plus to enjoy unlimited free returns.

Review the product
Product report

Description

Description

Circuit breaker 1P+N C 4A 10kA AC iC60H-C4-1N

  • Device application: Distribution
  • Product name: Acti 9 iC60
  • Product type: Circuit breaker
  • Poles: 1P + N
  • Number of protected poles: 1
  • Rated current: 4 A
  • Network type: Alternating current (AC)
  • Trip technology: Thermal-magnetic
  • Characteristic: C
  • Breaking capacity: 70 kA according to EN/IEC 60947-2
  • Usage category: Category A according to EN 60898-1
  • Isolation function: Yes according to EN 60947-2 and IEC 60947-2 standards
  • Network frequency: 50/60 Hz
  • Rated insulation voltage [Ui]: 500 V alternating current (AC)
  • Rated impulse withstand voltage [Uimp]: 6 kV according to EN 60947-2
  • Contact position indicator: Yes
  • Mounting base: On DIN rail
  • Height: 91 mm
  • Width: 36 mm
  • Depth: 78.5 mm
  • Product weight: 0.25 kg
  • Color: White
  • Mechanical durability: 20,000 cycles
  • Connections: Double terminal, rigid and flexible cable
  • Residual current protection: Separate block
  • Overvoltage category: IV
  • Ambient temperature: -35...70 °C

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Specifications

Number of Poles
1
Rated Current
4 A
Operating Curve
Curve C

Operating Curve

The tripping curve shows the time required for the circuit breaker to switch off in relation to the current passing through it. For small overcurrents, the tripping is delayed to avoid unnecessary interruptions, while for very high values, such as in the case of a short circuit, the breaker operates immediately to protect the circuit. Different types of curves are used depending on the needs of each installation and the type of loads.

Curve C

The most common in general installations, ideal for circuits with motors or electronic devices.

Power Supply

AC
Yes
DC
Yes

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications
Questions

Questions

Do you have a question about the product?

Those users who have this product can help you

Ask for the product

Description & Specifications

Circuit breaker 1P+N C 4A 10kA AC iC60H-C4-1N

  • Device application: Distribution
  • Product name: Acti 9 iC60
  • Product type: Circuit breaker
  • Poles: 1P + N
  • Number of protected poles: 1
  • Rated current: 4 A
  • Network type: Alternating current (AC)
  • Trip technology: Thermal-magnetic
  • Characteristic: C
  • Breaking capacity: 70 kA according to EN/IEC 60947-2
  • Usage category: Category A according to EN 60898-1
  • Isolation function: Yes according to EN 60947-2 and IEC 60947-2 standards
  • Network frequency: 50/60 Hz
  • Rated insulation voltage [Ui]: 500 V alternating current (AC)
  • Rated impulse withstand voltage [Uimp]: 6 kV according to EN 60947-2
  • Contact position indicator: Yes
  • Mounting base: On DIN rail
  • Height: 91 mm
  • Width: 36 mm
  • Depth: 78.5 mm
  • Product weight: 0.25 kg
  • Color: White
  • Mechanical durability: 20,000 cycles
  • Connections: Double terminal, rigid and flexible cable
  • Residual current protection: Separate block
  • Overvoltage category: IV
  • Ambient temperature: -35...70 °C

Manufacturer

Manufacturer Details

Warnings & Safety Information

Specifications

Number of Poles
1
Rated Current
4 A
Operating Curve
Curve C

Operating Curve

The tripping curve shows the time required for the circuit breaker to switch off in relation to the current passing through it. For small overcurrents, the tripping is delayed to avoid unnecessary interruptions, while for very high values, such as in the case of a short circuit, the breaker operates immediately to protect the circuit. Different types of curves are used depending on the needs of each installation and the type of loads.

Curve C

The most common in general installations, ideal for circuits with motors or electronic devices.

Power Supply

AC
Yes
DC
Yes

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
