Mounting method: DIN rail 35 mm
Color: Red
Type of insulating material: Thermoplastic
Flammability category of insulating material according to UL 94: V0
Bridged internal floors: No
Electrical connection:
Connection position: Side/Sideways
Explosion-proof version "EEx e": Yes
Locking plate required: Yes
Insulating element material: Thermoplastic
Cross-section of the connected single wire cable [mm2]: 0.5 to 4
Cross-section of the connected stranded cable without ring [mm2]: 0.5 to 2.5
Cross-section of the connected multi-core cable [mm2]: up to 4
Cross-section of the connected multi-core cable [mm2]: 1.5
Cross-section of the connected stranded cable with ring [mm2]: 0.5 to 2.5
Operating temperature range [°C]: from -60 to 130
Length [mm]: 46.5
Rated voltage [V]: 800
Rated current in [A]: 24
Number of terminals per floor: 2
Number of levels: 1
Width/size of raster [mm]: 5.1
Height at lowest installation [mm]: 60
