The KEMOT PROsinus-500 is an Uninterruptible Power Supply with a pure sine wave output. Designed to power various devices with a nominal voltage of 230 VAC and a maximum power of 500W, such as:
- central heating pumps, fireplaces
- other devices that require a maximum power of 500W (800W peak)
The clean voltage output ensures stable operation of the load, preventing overheating of inductive loads such as pumps or fans. Together with a 12V battery, it forms a complete uninterruptible power supply unit at 230 VAC. It is equipped with protection against battery overloading, short circuits, overvoltage, as well as protection from very high or very low battery voltage and overheating.
The device can operate in three modes:
- As an uninterruptible power supply with charging mode - allows voltage to pass from the grid to the charging and charges the external 12 VDC battery.
- As a rectifier - charges the external battery (the device must be connected to the 230V AC power source).
- As an inverter - converts the 12V DC voltage from the external battery to alternating voltage of 230V.
It is equipped with a clear and transparent LED display, indicating the operating status:
- Capacity
- Input voltage
- Output voltage and frequency
- Battery charge level
Technical specifications:
- Nominal power: 500W
- Battery type: 12V DC
- Maximum battery voltage: 15V DC
- Input voltage range: 190 ~ 260V AC
- Input voltage frequency: 45 ~ 60Hz
- Output voltage range: 230V AC +/- 8%
- Output frequency: 50 / 60Hz +/- 0.5Hz
- Output voltage waveform: pure sine wave
- Efficiency: 85% (DC-AC)
- Battery charging with a maximum current of 10A
Dimensions
- Power (Watt)
- 500 W
- Size
- Tower
- Output Waveform
- Pure Sine Wave
- Noise Level
- -
- Display Screen
- Digital Display
Connectivity
- USB
- Yes
