Additional Information:

• Manufacturer: ERKO
• Product Series: KCS
• Terminal Type: Eyelet
• Connection Angle: Straight
• Material: Copper
• Model: Without flange
• Wire Type: Multi-strand
• Metric Screw Connection Size: 4
• Insulated: NO
• With inspection hole: NO
• Surface protection: Silver plated
• Nominal cross-section [mm²]: 6

The copper eyelet terminals from the DIN series (electrolytic copper with zinc coating) are manufactured according to the DIN 46235 standard and are designed for compression. They allow for the connection of copper wires and are used where it is necessary to connect a wire to, for example, a distribution board, a rail, or other devices via a screw terminal. The use of DIN terminals increases the safety and durability of these connections.

All copper eyelet terminals undergo an additional hardening and burning process at a temperature of 700°C, which removes all impurities from the terminal material. The hardened terminals are less prone to cracking during compression, providing better working characteristics.

Material: electrolytic copper (according to EN13600).

Minimum rolling thickness: 3μ.

Dimensional tolerance according to DIN 46235.
