Dimensions

Provision

Single-Phase

Provision

Single-Phase

Operates with a standard 230V power supply, like a common household socket. Suitable for use in homes, garages, and small workshops.

Noise Level

97 dB

Noise Level: 97

The noise level is noticeable during operation, similar to that of a typical workshop or garage. The intensity level depends on the size and power of the compressor, with larger units producing a louder sound.

Portable

No

Weight

63 kg

Weight: 63

Stable constructions for permanent installation. Their transportation requires assistance or lifting equipment.

Performance

Power

3 hp

Power: 3

Supports most air tools, such as impact wrenches, nailers, and spray guns. Suitable for workshops and more demanding applications.

Maximum Pressure

10 bar

Maximum Pressure: 10

The maximum pressure that can be achieved determines the type of applications and tools that can be used.

Air Delivery

90 lt/min

Air Delivery: 90

Air delivery indicates how many liters of air the compressor can provide per minute. It is a key performance indicator, as it determines how much air is available for operating tools or applications. The higher the air delivery, the more demanding tasks it can support, such as continuous use of an impact wrench, sander, or painting.

Technical Features

Air Chamber

90 lt

Air Chamber: 90

The tank that stores the compressed air. It helps provide a steady supply and allows the compressor not to operate continuously.

Lubrication

With Oil

Lubrication

With Oil

The mechanism features an oil lubrication system, which distributes oil to the cylinders and pistons during operation. This ensures smooth movement of the parts, reduces wear due to friction, and increases the compressor's lifespan. It requires periodic maintenance and checking of the oil level.
