Main Features

• Cabinet design — sturdy construction and easy integration into technical spaces
• 28-liter ion-exchange resin, very fine mesh, for high ion exchange rate and better regeneration
• 2-in-1 function: water softening + removal of iron/manganese at high concentrations
• Up to ~60% salt savings & very low water consumption during regeneration
• Patented Dual Core valve with low resistance and high durability
• NSF/ANSI 44 certification for proven performance

Technical Details (Basic)

• Maximum capacity: 2,061 g hardness removal
• Compensated hardness: 1,540 mg/L
• Maximum Fe removal: 10 ppm (final ≤0.3 ppm)
• Flow rate factor: 20.8 L/min @1 bar
• Operating temperature: 4°–49 °C
• Input pH: ≥7
• Connection: 1″ MNPT
• Tank dimensions: 26.7 × 66 cm
• Height: 79.5 cm
• Resin: 28 L Fine Mesh Resin

Installation & Operation

• A drain line ≥1.6 cm (ID) is required for proper regeneration cycle operation
• The maximum drain flow (7.6 L/min) must be fully maintained
• Large, easy-to-read display on the controller
• High performance even at low pressures

Why Choose This Model

• Ideal for larger homes, two-story buildings, or areas with high water demands
• High capacity for softening & iron removal
• Extremely economical in salt and water use
• Upgraded durability and high reliability
• NSF certified performance

Maintenance

• Very fine mesh resin, chlorine resistant, with long lifespan
• Regular salt addition & periodic regeneration setting checks
