Main Features
- Cabinet design — sturdy construction and easy integration into technical spaces
- 28-liter ion-exchange resin, very fine mesh, for high ion exchange rate and better regeneration
- 2-in-1 function: water softening + removal of iron/manganese at high concentrations
- Up to ~60% salt savings & very low water consumption during regeneration
- Patented Dual Core valve with low resistance and high durability
- NSF/ANSI 44 certification for proven performance
Technical Details (Basic)
- Maximum capacity: 2,061 g hardness removal
- Compensated hardness: 1,540 mg/L
- Maximum Fe removal: 10 ppm (final ≤0.3 ppm)
- Flow rate factor: 20.8 L/min @1 bar
- Operating temperature: 4°–49 °C
- Input pH: ≥7
- Connection: 1″ MNPT
- Tank dimensions: 26.7 × 66 cm
- Height: 79.5 cm
- Resin: 28 L Fine Mesh Resin
Installation & Operation
- A drain line ≥1.6 cm (ID) is required for proper regeneration cycle operation
- The maximum drain flow (7.6 L/min) must be fully maintained
- Large, easy-to-read display on the controller
- High performance even at low pressures
Why Choose This Model
- Ideal for larger homes, two-story buildings, or areas with high water demands
- High capacity for softening & iron removal
- Extremely economical in salt and water use
- Upgraded durability and high reliability
- NSF certified performance
Maintenance
- Very fine mesh resin, chlorine resistant, with long lifespan
- Regular salt addition & periodic regeneration setting checks
- Product Number
- 519419
- Type
- Resin
- Laundry
- No
- Capacity
- 28 lt
- Spare Part
- No
