Stainless steel GOSHE pipe manifold with 5 circuits.

• Steel beams: 2 pcs
• Bracket: 2 pcs
• Control valves with flow meters: 2 pcs
• Thermostatic valves: 2 pcs
• Brass bottles: 2 pcs
• Automatic air release valves 1/2": 2 pcs
• Drain valves: 2 pcs

Technical specifications:

• Maximum operating pressure: 10 Bar
• Maximum operating temperature: 100°C
• Beam dimension: 235 mm
• Section dimension: 50 mm
• Equipped with rubber vibration dampers
• Flow rate meters - 2.5 l/min

Materials:

• Beam - AISI 304 steel (40 mm x 40 mm)
• Nipples, bottles - brass CWN617

Flow meter:

• Accurate measurement scale: allows determining the flow in the system and confirming proper operation.
• Durable: the flow meter is highly resistant to chemicals and mechanical damage.
• Solid construction: made of brass and plastic materials, ensuring long-term use.
• Guaranteed tightness: the product design and additional sealing prevent leaks and inaccurate measurements.

Technical specifications for the flow meter:

• Total length: 100 mm
• Connection thread: 1/2'' GZ DN15
• Material of the split sections: Brass
• Reading/adjustment range: 0-2.5 L/min
