Artpol Wood Cutting Disc with 16 Blades 115mm

The cutting disc consists of thermally treated 50# carbon steel and YG8 tungsten carbide on the cutting edge, with an edge hardness of 85 HRc (+/-2st). The GS edge geometry has an attack angle of 10st...

The cutting disc consists of thermally treated 50# carbon steel and YG8 tungsten carbide on the cutting edge, with an edge hardness of 85 HRc (+/-2st). The GS edge geometry has an attack angle of 10st. The metal disc, laser-cut, offers rigidity and limits stress under high load and elevated temperature. The welded HM carbide allows for repeated sharpening.

...

See full description See full description
16 36 €
17 Coins 17 Coins
Delivery Tue, 13 Oct - Mon, 19 Oct
2,50 € to a Skroutz Point
or   3,50 €   shipping cost
Do you want it with Free shipping to Skroutz Point?
From Agmia 5.0 (3)
Πειραιάς, Αττικής
20+ pieces
See Power Tool Accessories on the page of Agmia
What if I change my mind?

No problem, as long as it's within 14 days. We'll come pick it up or you can choose the Skroutz Point that suits you, completely free for up to 2 times per year, and we'll refund your money. Get Skroutz Plus to enjoy unlimited free returns.

Description

Description

The cutting disc consists of thermally treated 50# carbon steel and YG8 tungsten carbide on the cutting edge, with an edge hardness of 85 HRc (+/-2st). The GS edge geometry has an attack angle of 10st. The metal disc, laser-cut, offers rigidity and limits stress under high load and elevated temperature. The welded HM carbide allows for repeated sharpening.

The edge geometry and the shape of the GS10 plate (alternating bevels) enable processing during cross-cutting of wood. The larger number of teeth at this diameter contributes to smooth surfaces, especially on dry wood. It can also be used for longitudinal cutting, but a disc with fewer teeth is recommended for higher cutting speed.

It is intended for industrial applications with electric tools, for soft and hard wood, wood-based materials, fiberboard, and drywall. The technical specifications include:

  • Maximum rotation speed: 10,000 rpm
  • Inner bore: fi 22.2mm
  • Inner bore reductions: 22.2x12.6mm, 22.2x16.0mm, 22.2x18.0mm, 22.2x20.0mm
  • Diameter: fi 115mm
  • Number of teeth: 16

For better cutting quality and longer life, it is recommended that the cutting edge protrude by w/3 of its height above the thickness of the material during cutting. It is not intended for concrete, bricks, terracotta, ceramics, plexiglass and other plastics, ferrous and non-ferrous metals, or wood-based materials bonded with other materials.

Manufacturer

See full description

Specifications

Specifications

Specifications

Cutting Material
Wood
Blade
16 T
Pieces
1 pcs

Dimensions

Diameter
115 mm

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications
Questions

Questions

Do you have a question about the product?

Those users who have this product can help you

Ask for the product

Description & Specifications

The cutting disc consists of thermally treated 50# carbon steel and YG8 tungsten carbide on the cutting edge, with an edge hardness of 85 HRc (+/-2st). The GS edge geometry has an attack angle of 10st. The metal disc, laser-cut, offers rigidity and limits stress under high load and elevated temperature. The welded HM carbide allows for repeated sharpening.

The edge geometry and the shape of the GS10 plate (alternating bevels) enable processing during cross-cutting of wood. The larger number of teeth at this diameter contributes to smooth surfaces, especially on dry wood. It can also be used for longitudinal cutting, but a disc with fewer teeth is recommended for higher cutting speed.

It is intended for industrial applications with electric tools, for soft and hard wood, wood-based materials, fiberboard, and drywall. The technical specifications include:

  • Maximum rotation speed: 10,000 rpm
  • Inner bore: fi 22.2mm
  • Inner bore reductions: 22.2x12.6mm, 22.2x16.0mm, 22.2x18.0mm, 22.2x20.0mm
  • Diameter: fi 115mm
  • Number of teeth: 16

For better cutting quality and longer life, it is recommended that the cutting edge protrude by w/3 of its height above the thickness of the material during cutting. It is not intended for concrete, bricks, terracotta, ceramics, plexiglass and other plastics, ferrous and non-ferrous metals, or wood-based materials bonded with other materials.
