Power: 3.5 KW

Capacity: 160 lt

Roof: Double energy

Collector frame and back: made of anodized aluminum

Collector surface: with blue selective coating from selective aluminum sheets 0.5mm thick, welded with laser technology

Thermal Absorption: 95% ±2%

Pressure: 5 bar

Number of Collectors: 1

Maximum operating pressure: 15 bar

Collector Insulation: Glass wool insulation on the back 50mm thick and rock wool on the sides 20mm thick

Base material: Hot-dip galvanized iron angle

Internal Protection: Hot water storage tank made of special steel DIN 1203-St 37-2 2.5mm enameled according to DIN 4753 Teil3 enamel

Collector Type: Selective

Collector Surface: 1.95 sq.m.

Tank Type: Glass

Safety valve: Available

Adjustable thermostat: Available

Safety glass: Available

Equipment and Accessories:

• 1 Solar Tank
• 1 Selective Collector
• 1 Solar Base
• Accessories
• Solar Thermal Fluid

Dimensions (LxWxH): 59 x 57 x 141 cm Tank
